Main Specifications |
Device Type | SuperChassis |
Dimensions (WxDxH) | Height 1.7" (43 mm) x Width 17.2" (437 mm) x Depth 27.75" (705 mm) |
Color | Black |
Form Factor | 1U chassis support for max. motherboard size - 16.48" x 14.3" (Quad-processor motherboards) |
Weight | 42 lbs (18.95 kg) |
Processor |
Compatible Processors | Quad AMD Socket F Processors |
Expansion / Connectivity |
Expansion Slots Total (Free) | 1x full-height, Full-length expansion slot (Riser card required) |
Peripheral Drives |
DVD-ROM | Slim DVD-ROM drive (optional) |
Drive Bays |
Hot-swap | 3x 3.5" hot-swap U320/160 SAS / SATA drive bays with SES2 - SAS or enterprise SATA HDD only recommended |
Peripheral Drives | CSE-PT93L-B |
System Cooling |
Fans | 7x 40x56mm 4-pin PWM cooling fans |
| FAN-0101L4 - Fan Holder: MCP-320-00027-0B, MCP-320-00028-0B, MCP-320-00029-0B, MCP-320-00030-0B |
Operating Environment (System) |
Operating Temperature Range | Non-Operating Relative Humidity Range 5% - 95% (non-condensing) |
| Operating Temperature Range 5C - 35C (41F - 95F) |
| Non-Operating Temperature Range -40C - 70C (-40F - 158F) |
| Operating Relative Humidity Range 8% - 90% (non-condensing) |
Power Supply |
Certification | 80 PLUS Gold Certified |
Power Supply | 1400W high-efficiency power supply with PMBus |
| Power Supply PWS-1K41F-1R - Power Distributor PDB-PT818-8824 |
SAS / SATA Backplane |
SAS / SATA Backplane | SAS HDD Backplane with SES2 |
Regulatory (Power Supply) |
Power Supply Safety / EMC | USA - UL listed, FCC, Canada - CUL listed, Europe/CE Mark, EN 60950/IEC 60950-Compliant, Germany - TUV Certified, CCC Certification |
Standard Parts List |
Accessory | CSE-PT94L-B, PWS & Accessory: CSE-PT0126, MCP-250-00001-00 |
Chassis | CSE-818TQ-1400LPB |
Front Panel | MCP-280-81301-0N |
Rear Window | MCP-240-81807-0N, MCP-240-81808-0N |
Parts List - (Items Included) |
Backplane | BPN-SAS-818TQ |
Drive Trays | CSE-PT39-B0 |
Mounting Rails | MCP-290-00016-0N, MCP-290-00042-0V |
Parts List |
Cables | CBL-0044L, CBL-0087, CBL-0154L, CBL-0160L |
