| Main Specifications |
| Dimensions (WxDxH) | Height 1.7" (43 mm) x Width 16.8" (426 mm) x Depth 21.95" (558 mm) |
| Color | Black |
| Form Factor | 21.9" Depth 1U Rackmount Chassis - support for motherboard sizes of 12" x 13" and 13.68" x 13" |
| Weight | 29 lbs (13.2kg) |
| Processor Support |
| Processor Support | Supports dual, single Intel / AMD processors |
| Expansion / Connectivity |
| Expansion Slots Total (Free) | 1x Full-height, Full-length AOC expansion slot |
| Peripheral Drives |
| DVD-ROM | Slim DVD-ROM drive (optional) |
| Drive Bays |
| Hot-swap | 4x Hot-swap 2.5" SAS / SATA HDD trays - SAS or enterprise SATA HDD only recommended |
| Front Panel |
| Buttons | Power On/Off button, System Reset button |
| LEDs | Power status LED, HDD activity LED, 2x Network activity LEDs |
| System Cooling |
| Fans | 3x 40x56mm 4-pin PWM fans - 2x 40x28mm 4-pin PWM fans for add-on card (optional) |
| FAN-0101L4 |
| Operating Environment (System) |
| Operating Temperature Range | Operating Temperature Range 10 - 35C (50 - 95F) |
| Non-Operating Temperature Range -40 - 70C (-40 - 158F) |
| Humidity Range 8 - 90% non-condensing |
| Non-Operating Humidity Range 5 - 95% non-condensing |
| Power Supply |
| Certification | 80PLUS Gold Certified |
| Power Supply | 560W AC power supply w/ PFC (24-pin) |
| PWS-563-1H |
| SAS / SATA Backplane |
| SAS / SATA Backplane | 1U 2.5" SAS / SATA HDD backplane |
| Regulatory (Power Supply) |
| Power Supply Safety / EMC | USA - UL listed, FCC, Canada - CUL listed, CCC Certification, EN 60950/IEC 60950-Compliant, Europe/CE Mark, Germany - TUV Certified |
| Standard Parts List |
| Accessory | MCP-420-11101-0N, MCP-290-11104-0B, MCP-290-00033-0N |
| Chassis | CSE-111TQ-563CB |
| Peripheral Drive Bay | MCP-290-11101-0B |
| Rear Window | MCP-240-11102-0N |
| Parts List - (Items Included) |
| Air Shroud | MCP-310-18004-0N |
| Backplane | BPN-SAS-809TQ |
| Drive Trays | MCP-220-00047-0B |
| Mounting Rails | MCP-290-00050-0N |
| Parts List |
| Cables | CBL-0277L, CBL-0306L |
