  2. Intel CD8069504344600 Xeon Bronze 3206R 1.90GHz 8-Core Processor 2nd Generation - Cascade Lake
Intel CD8069504344600 Xeon Bronze 3206R 1.90GHz 8-Core Processor 2nd Generation - Cascade Lake

Intel CD8069504344600 Xeon Bronze 3206R 1.90GHz 8-Core Processor 2nd Generation - Cascade Lake

  • For small business and basic storage servers

  • Faster Time to Value with Intel Select Solutions

  • Entry-level Performance and HW-enhanced Security

  • 1.9GHz Frequency, 8 Core/8 Thread, 8.25MB Cache

1.9GHz Xeon Bronze 3206R Processor Gen.2, 8-Cores (8 Threads), FCLGA3647, 11MB Cache, 9.6GT, 2UPI, 85W, 14nm Intel Xeon Scalable Processors 2nd Generation - OEM

This product is no longer available.

  • Faster Time to Value with Intel Select Solutions

  • Strong, Capable Platforms for the Data-Fueled Enterprise

  • Next-Generation Platform for Cloud-Optimized, 5G-Ready Networks, and Next-Generation Virtual Networks

Extra Specifications for Intel CD8069504344600 Xeon Bronze 3206R 1.90GHz 8-Core Processor 2nd Generation - Cascade Lake

Main Specifications
Device TypeProcessor
Processor NumberIntel Xeon Bronze 3206R
Multi-Core Technology8-core
Number of Threads8 threads
Clock Speed1.9 GHz
Manufacturing Process14 nm
Product Collection2nd Generation Intel Xeon Scalable Processor
Code NameProducts formerly Cascade Lake
Vertical SegmentServer
Processor
CacheSmart Cache - 11 MB
Thermal
Design Power85 W
Specification78C
Memory Specifications
Max Memory Size (dependent on memory type)1 TB
Memory TypesDDR4-2133
Maximum Memory Speed2133 MHz
Max # of Memory Channels6
ECC Memory SupportedYes
Intel Optane DC Persistent Memory SupportedNo
Expansion Options
Scalability2S
PCI Express Revision3.0
Max # of PCI Express Lanes48
Security Features
Security FeaturesIntel AES New Instructions, Intel Trusted Execution Technology, Execute Disable Bit, Mode-based Execute Control (MBE)
Miscellaneous
FeaturesEnhanced SpeedStep technology, SpeedStep technology, Hyper-Threading Technology, Execute Disable Bit capability, Intel Virtualization Technology, Intel 64 Technology, Intel Trusted Execution Technology, streaming SIMD extensions 4.2, Intel AES New Instructions (AES-NI), Intel Virtualization Technology for Directed I/O (VT-d), Intel vPro Technology, Intel VT-x with Extended Page Tables (EPT), Intel Advanced Vector Extensions 2 (AVX2.0), Intel Transactional Synchronization Extensions (TSX), Intel Optane Memory Supported, Intel Advanced Vector Extensions 512 (AVX-512), Mode-based Execute Control (MBE), Intel Volume Management Device (VMD), Intel Run Sure Technology, Intel Deep Learning Boost (DL Boost), Intel Resource Director Technology (RDT), Advanced Vector Extensions (AVX)
Package TypeOEM, Tray
Package Specifications
Sockets SupportedFCLGA3647
Case Temperature78°C
Package Size76.0mm x 56.5mm
