| Main Specifications |
| Device Type | SuperChassis |
| Form Factor | 1U Chassis |
| Supported Mainboards | Supports 2 proprietary 16" x 6.5 " (40.6cm x 16.5cm) motherboards |
| Dimensions (WxDxH) | Height 1.7" (43mm) x Width 17.2" (437mm) x Depth 27.75" (705mm) |
| Weight | 40 lbs (18.2 kg) |
| Enclosure Color | Black |
| Processor Support |
| Processor Support | Supports Twin motherboards with dual, single Intel Xeon / AMD Opteron processors |
| Expansion Slots |
| Expansion Slots (per node) | 1x low-profile expansion slot (Riser Card Required) |
| Drive Bays |
| Hot-swap (per Node) | 2x 3.5" SAS/SATA Hot-swap drive bays (supports SES2 drives) - SAS or enterprise SATA HDD only recommended |
| SAS/SATA Backplane |
| SAS/SATA Backplane | 1x 1U SAS/SATA backplane |
| System Cooling |
| Fans | 3x 4-pin PWM Cooling Fans (per Node) |
| Front Panel |
| Buttons (per Node) | Power On/Off button, System Reset button |
| LEDs (per Node) | Power LED, Hard drive activity LED, 2x Network activity LEDs, System Overheat LED |
| Environmental |
| Operating Environment | Operating Temperature Range: 5°C - 35°C (41°F - 95°F) |
| Operating Relative Humidity Range: 8% - 90% (non-condensing) |
| Non-Operating Relative Humidity Range: 5% - 95% (non-condensing) |
| Non-Operating Temperature Range: -40°C - 60°C (-40°F - 140°F) |
| Power Supply |
| Power Supply | 1280W High-Efficiency (95%+) power supply |
| Certification | 80PLUS Platinum Certified |
| Regulatory Safety / EMC | USA - UL listed, Canada - CUL listed, TUV Certified, EN 60950/IEC 60950-Compliant, CB Report, CCC Certification |
| Parts List - (Items Included) |
| Air Shroud | 2x MCP-310-18008-0N |
| Backplane | 1x BPN-SAS-808 |
| Cable | 2x CBL-0087, 1x CBL-0160L, 1x CBL-0201L, 2x CBL-0212L |
| Fan(s) | 2x MCP-290-00033-0N |
| Front Panel | 2x MCP-280-00020-0N |
| Drive Trays | 4x MCP-220-00001-01 |
| Mounting Rails | 1x MCP-290-00042-0V |
| Parts | 1x MCP-250-80801-0N, 1x MCP-270-00010-00, 1x MCP-160-80802-0N |
| Power Supply Number | 1x PWS-1K21P-1R |
| Power Distributor(s) | 1x PDB-PT808-S20 |
| Miscellaneous |
| Compatible Motherboards | X10DRT-L, X10DRT-LIBF, X10DRT-LIBQ |
