- Supermicro CSE-829BTQ-R920WB 2U Rackmount 920W Redundant Power Supply
Supermicro CSE-829BTQ-R920WB 2U Rackmount 920W Redundant Power Supply
Support Intel and AMD processors
10x 3.5 hot-swap SAS/SATA drive bay
SAS3 12Gbps single-expander backplane
920W Redundant Platinum Super Quiet power supply
2U Rackmount 920W Redundant Platinum Super Quiet Power Supply for SMC Proprietary WIO motherboard up to 13.68in x 16.5in, support dual Intel / AMD processors, up to 10x SAS/SATA 3.5in drives, 4x Full-Height, Full-Length Slots - SC829BTQ-R920WB
2U chassis supports for maximum motherboard sizes - SMC Proprietary WIO , 13.68" x 16.5" motherboards
10 x 3.5" hot-swap SAS/SATA
10-port 2U CSE-829 TQ (W/ AMI 9072 SGPIO support) backplane, support up to 10x 3.5-inch SAS/SATA HDD
1U 920W Redundant Platinum Super Quiet power supply W/PMbus
4 full-height & full-length expansion slot(s) , 3 low-profile expansion slot(s)
4 x 80mm 9500 RPM fan(s)
Optional 3 x fans for 100% cooling redundancy
Extra Specifications for Supermicro CSE-829BTQ-R920WB 2U Rackmount 920W Redundant Power Supply
| Main Specifications | ||
| Device Type | SuperChassis 829BTQ-R920WB | |
| Form Factor | 2U chassis | |
| Supported Motherboards | SMC Proprietary WIO , 13.68" x 16.5" motherboards | |
| Dimensions (WxDxH) | Height 3.5" (89 mm) x Width 17.2" (437 mm) x Depth 27.75" (705 mm) | |
| Weight | 55 lbs (24.95 kg) | |
| Enclosure Color | Black | |
| Processor Support | ||
| Processor Support | Dual Intel and AMD processors | |
| Expansion / Connectivity | ||
| Expansion Slots Total (Free) | 3 low-profile expansion slot(s) | |
| 4 full-height & full-length expansion slot(s) | ||
| Drive Bays | ||
| Hot-swap | 10 x 3.5" hot-swap SAS/SATA | |
| Peripheral Drives | Optional 1 x slim DVD-ROM drive bay | |
| Optional 2 x USB 2.0 ports | ||
| 1 x COM port tray | ||
| Backplane | ||
| SAS/SATA HDD Backplane | 10-port 2U CSE-829 TQ (W/ AMI 9072 SGPIO support) backplane, support up to 10x 3.5-inch SAS/SATA HDD | |
| HDD Backplane | 1x BPN-SAS-829BTQ | |
| Front Panel | ||
| Buttons | Power On/Off button, System Reset button | |
| LEDs | 4 Network Activity LEDs, HDD activity LED, Power Status LED, Power Fail LED, System Information LED | |
| System Cooling | ||
| Fans | 4 x 80mm 9500 RPM fan(s) | |
| Optional 3 x fans for 100% cooling redundancy | ||
| Environmental Parameters | ||
| Operating Temperature | Non-Operating Temperature Range: -40°C - 70°C (-40°F - 158°F) | |
| Operating Relative Humidity Range: 8% - 90% (non-condensing) | ||
| Non-Operating Relative Humidity Range: 5% - 95% (non-condensing) | ||
| Operating Temperature Range: 5°C - 35°C (41°F - 95°F) | ||
| Power Supply | ||
| Power Supply | 1U 920W Redundant Platinum Super Quiet power supply W/PMbus | |
| Certification | 80 Plus Platinum Certified | |
| Regulatory Safety / EMC | BSMI, CCC, CE/EMC, FCC class B, TUV/CB, UL/CUL | |
| Parts List - (Items Included) | ||
| Air Shroud | 1x MCP-310-29002-0N | |
| Cable(s) | 1x CBL-0071, 1x CBL-0157L, 1x CBL-0180L-01 | |
| Fan(s) | 4x FAN-0118L4 | |
| Drive Trays | 10x MCP-220-00075-0B | |
| Power Supply Number | 2x PWS-920P-SQ | |
| Mounting Rails | 1x MCP-290-00053-0N | |
| Rear Window | 1x MCP-240-00104-0N | |
| Miscellaneous | ||
| Included Accessories | 1x MCP-290-00036-0B, 1x MCP-320-82902-0N | |
| Compatible Motherboards | X9DRW-3LN4F+, X9DRW-3TF+, X9DRW-iTPF, X9DRW-iTPF+, X9DRW-7TPF | |
| Compatible Servers | 6027R-N3RFT+, 6027R-N3RF4+, 6027R-72RFTP+ | |
| Warranty: | 3 years labor, 1 year parts, 120 days advance replacement (doa) |
| Coverage: | Replacement or repair |
| Average Service Time: | Overnight replacement for 120 days, 2 weeks afterward |
| E-mail: | returnservices@wiredzone.com |
| If you need Technical Support for this item please contact: | |
| Provider: | Supermicro |
| Type of Support: | FULL |
| Phone No.: | 408-503-8000 |
| URL: | Click here for Manufacturer Website |
