3.8GHz Frequency, 2 Core/4 Thread, 4 MB Cache
Intel Hyper-Threading Technology, Intel Boot Guard
Triple Display Capable, Integrated Intel UHD Graphics 610
Use Conditions Embedded Broad Market Commercial Temp
Processor 3.8GHz Pentium Gold G6400E 2-Core (4 Threads), FCLGA1200, 8GT/s, 4MB, 14nm, 58W, UHD Graphics 610, 1P, OEM
Discover an amazing balance of performance, experience, and value with systems powered by Intel Pentium processors. Collaborate, create, and play with ease.
| Main Specifications | ||
| Device Type | Processor | |
| Processor Number | G6400E | |
| Clock Speed | 3.80GHz | |
| Multi-Core Technology | 2-Core | |
| Number of Threads | 4-Thread | |
| Manufacturing Process | 14 nm | |
| Bus Speed | 8 GT/s | |
| Product Collection | Intel Pentium Gold Processor Series | |
| Code Name | Products formerly Comet Lake | |
| Vertical Segment | Embedded | |
| Processor | ||
| Cache | 4 MB Intel Smart Cache | |
| Thermal | ||
| Design Power | 58 W | |
| Memory Specifications | ||
| Max Memory Size (dependent on memory type) | 128 GB | |
| Memory Types | DDR4-2400 | |
| Max # of Memory Channels | 2 | |
| Max Memory Bandwidth | 37.5 GB/s | |
| ECC Memory Supported | No | |
| Integrated Graphics | ||
| Type | Intel UHD Graphics 610 | |
| Base Frequency | 350 MHz | |
| Max Dynamic Frequency | 1.05 GHz | |
| Max Supported Memory Size | 64 GB | |
| Max Supported Resolution | 4K Support Yes, at 60Hz, (HDMI) 4096x2160@30Hz, (DP) 4096x2304@60Hz, (eDP) 4096x2304@60Hz | |
| Features IG | Intel Quick Sync Video, Intel InTru 3D Technology, Intel Clear Video HD Technology, Intel Clear Video Technology, # of Displays Supported 3 | |
| Expansion Options | ||
| Scalability | 1S | |
| PCI Express Revision | 3.0 | |
| PCI Express Configurations | Up to 1x16, 2x8, 1x8+2x4 | |
| Max # of PCI Express Lanes | 16 | |
| Package Specifications | ||
| Sockets Supported | FCLGA1200 | |
| Max CPU Configuration | 1 | |
| Thermal Solution Specification | PCG2015C | |
| Case Temperature | 100°C | |
| Package Size | 37.5mm x 37.5mm | |
| Miscellaneous | ||
| Features | Intel Hyper-Threading Technology, Intel Virtualization Technology, Intel Virtualization Technology for Directed I/O, Intel VT-x with Extended Page Tables, Intel 64, Instruction Set: 64-bit, Instruction Set Extensions: Intel SSE4.1, Intel SSE4.2, Idle States, Enhanced Intel SpeedStep Technology, Thermal Monitoring Technologies, Intel Identity Protection Technology | |
| Use Conditions | Embedded Broad Market Commercial Temp | |
| Package Type | OEM, Tray | |
| Security Features | ||
| Security Features | Intel AES New Instructions, Secure Key, Intel Software Guard Extensions (Intel SGX): Yes with Intel ME, Intel OS Guard, Execute Disable Bit, Intel Boot Guard | |
