| Main Specifications |
| Device Type | SuperChassis |
| Form Factor | 3U chassis support for motherboard size - E-ATX and ATX. |
| Dimensions (WxDxH) | Height 5.2" (132 mm) x Width 17.2" (437 mm) x Depth 25.5" (647 mm) |
| Weight | 75 lbs (34.02 kg) |
| Enclosure Color | Black |
| Processor |
| Compatible Processors | Dual and Single Intel and AMD processors |
| Expansion / Connectivity |
| Expansion Slots Total (Free) | 7 full-height & full-length expansion slot(s) |
| Expansion Bays Total (Free) | 8 x 3.5" hot-swap SAS/SATA, 2 x 5.25" drive bay |
| Peripheral Bay (Free) | 1 x slim DVD-ROM drive bay |
| SAS / SATA Backplane |
| SAS / SATA Backplane | SAS833/835 BACK PANEL WITH AMI MG9072 |
| Front Panel |
| Buttons | Power On/Off button, System Reset button |
| LEDs | 2 Network Activity LEDs, HDD activity LED, Power LED, Power Fail LED, System Overheat LED |
| System Cooling |
| Fans | 3 x 80mm Hot-swap PWM Fans |
| 2 x 80mm rear hot-swap exhaust PWM fan(s) |
| System Monitoring |
| System Monitoring | Chassis intrusion switch |
| Environmental |
| Operating Environment | Operating Temperature Range: 5°C - 35°C (41°F - 95°F) |
| Non-Operating Temperature Range: -40°C - 70°C (-40°F - 158°F) |
| Operating Relative Humidity Range: 8% - 90% (non-condensing) |
| Non-Operating Relative Humidity Range: 5% - 95% (non-condensing) |
| Power Supply |
| Power Supply | 1U 920W Redundant Platinum Super Quiet power supply W/PMbus |
| Certification | 80PLUS Platinum Certified |
| Regulatory Safety / EMC | BSMI, CCC, CE/EMC, FCC class B, TUV/CB, UL/CUL |
| Parts List - (Items Included) |
| Air Shroud | 1x MCP-310-39001-0N |
| Backplane | 1x CSE-SAS-833TQ |
| Cable | 4x CBL-0044L, 1x CBL-0071L, 5x CBL-0216L |
| Parts | 1x DVM-HLDS-DVD-SBT1 |
| Fan(s) | 2x FAN-0125L4, 3x FAN-0126L4 |
| Drive Trays | 2x MCP-220-00009-01, 8x MCP-220-00075-0B |
| Power Distributor(s) | 1x PDB-PT825-8824 |
| Power Supply Number | 2x PWS-920P-SQ |
| Mounting Rails | 1x MCP-290-00053-0N |
