- Supermicro AOC-653105A-HDAT ConnectX-6 HDR/200GbE InfiniBand Ethernet Adapter Card - Gen 4 PCIe x16 (16GT/s) Single-Port QSFP56 Connectors
Supermicro AOC-653105A-HDAT ConnectX-6 HDR/200GbE InfiniBand Ethernet Adapter Card - Gen 4 PCIe x16 (16GT/s) Single-Port QSFP56 Connectors
Efficient service chaining enablement
Block-level XTS-AES mode hardware encryption
Host Chaining technology for economical rack design
Flexible programmable pipeline for new network flows
ConnectX-6 VPI Adapter Card HDR InfiniBand and 200GbE Single-Port QSFP56 Gen 3/4 8.0GT/s/16GT/s, PCIe x16 Tall Bracket - NVIDIA MCX653105A-HDAT-SP (Single Pack)
ConnectX-6 Virtual Protocol Interconnect provides two ports of 200Gb/s for InfiniBand and Ethernet connectivity, enabling high performance and flexible solutions for demanding data center applications. ConnectX-6 is a groundbreaking addition to the Mellanox ConnectX series of adapter cards. In addition to all the existing innovative features of past versions, ConnectX-6 offers a number of enhancements to further improve performance and scalability.
Features
High throughput, low latency, low CPU utilization, and high message rate
High performance and intelligent fabric for compute and storage infrastructures
Advanced storage capabilities
Host Chaining technology for economical rack design
Intelligent network adapter supporting flexible pipeline programmability
Enabler for efficient service chaining capabilities
Efficient I/O consolidation, lowering data center costs and complexity
Extra Specifications for Supermicro AOC-653105A-HDAT ConnectX-6 HDR/200GbE InfiniBand Ethernet Adapter Card - Gen 4 PCIe x16 (16GT/s) Single-Port QSFP56 Connectors
Main Specifications | ||
Device Type | Network adapter - 1 port | |
Form Factor | Plug-in Card | |
Interface (Bus) Type | PCI Express 4.0 x16 | |
PCI Specification Revision | PCIe 1.1, PCIe 2.0, PCIe 3.0 | |
Networking | ||
Ports | 200Gb Ethernet / 200Gb Infiniband QSFP28 x 1 | |
Data Link Protocol | Gigabit Ethernet, 10 Gigabit Ethernet, 40 Gigabit Ethernet, 100 Gigabit Ethernet, 25 Gigabit Ethernet, 50 Gigabit Ethernet, 100 Gigabit InfiniBand, 200 Gigabit Ethernet, 200 Gigabit InfiniBand | |
Network / Transport Protocol | TCP/IP, UDP/IP, iSCSI | |
Storage Controller | ||
Connectivity Technology | Wired | |
Data Transfer Rate | 200 Gbps | |
Expansion / Connectivity | ||
Expansion / Connectivity | 1 x 200Gb Ethernet / 200Gb Infiniband - QSFP28 | |
Software / System Requirements | ||
OS Required | FreeBSD, Microsoft Windows, Red Hat Enterprise Linux, CentOS | |
Miscellaneous | ||
Compliant Standards | RoHS | |
Compliant Standars | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3ap, IEEE 802.3az, IEEE 802.3ba, IEEE 802.1AX, IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 802.1Qau, IBTA 1.3, IEEE 802.1Qbg, IEEE 1588v2, IEEE 802.3bj, IEEE 802.3bm, IEEE 802.3by | |
Features | Auto-negotiation, MPLS support, VLAN support, InfiniBand QDR Link support, Virtual Protocol Interconnect (VPI), Quality of Service (QoS), InfiniBand DDR Link support, Jumbo Frames support, PXE support, Large Send Offload (LSO), Large Receive Offload (LRO), Receive Side Scaling (RSS), UEFI support, InfiniBand FDR Link support, congestion control, Advanced Error Reporting (AER), Extended Message-Signaled Interrupts (MSI-X), Header Data Split (HDS), Transmit Side Scaling (TSS), RDMA over Converged Ethernet (RoCE), InfiniBand EDR Link support, TLP Processing Hint (TPH), InfiniBand SDR Link support, Extended Reliable Connected transport (XRC), Dynamically Connected transport (DCT), user mode registration and remapping of memory (UMR), On demand paging (ODP), Message Signaled Interrupts (MSI), InfiniBand HDR100 Link support |
Warranty: | 3 years labor, 1 year parts, 120 days advance replacement (doa) |
Coverage: | Replacement or repair |
Average Service Time: | Overnight replacement for 120 days, 2 weeks afterward |
