- Supermicro SSG-620P-ACR16L Storage DP 2U Barebone Dual 3rd Gen Intel Xeon Scalable processors Up to 4TB RDIMM/LRDIMM/Intel DCPMM SATA3, SAS3, NVMe hybrid, M.2 Dual 10GbE, IPMI LAN port
Supermicro SSG-620P-ACR16L Storage DP 2U Barebone Dual 3rd Gen Intel Xeon Scalable processors Up to 4TB RDIMM/LRDIMM/Intel DCPMM SATA3, SAS3, NVMe hybrid, M.2 Dual 10GbE, IPMI LAN port
• Enterprise Server
• iSCSI SAN
• HPC, Data Center
• Database Processing & Storage
• Corporate Database
Barebone 2U Rackmount SuperServer 3rd Gen Intel Xeon Scalable processors, Intel C621A chipset, Up to 4TB in 16 DIMM slots, LRDIMM/RDIMM + 2 Intel Optane Persistent Memory Dedicated Slots, SAS3 via Broadcom 3816 Controller, 16x 3.5in SATA3/SAS3 drive bays (4x 3.5in NVMe hybrid), 1x M.2 NVMe, 2x 10GbE BaseT LAN Ports, IPMI LAN port, 2 SuperDOM (Disk on Module) port, 1600W Redundant Power Supply (CSE-829HE1C4-R1K62LPB + X12DPi-NT6)
This product is no longer available.
1. Dual Socket P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable Processors
2. 16 ECC DDR4-3200: LRDIMM/RDIMM + 2 Intel® Optane™ Persistent Memory Dedicated Slots
3. 2x 10Gbe
4. 16x 3.5" hot-swap hybrid SATA/SAS drive bays (4 NVMe Hybrid Ports); 2 Rear SATA Slots; onboard 1 M.2 NVMe
5. 3 heavy duty fans with optimal fan speed control; 1 Air Shroud
6. 1600W Redundant Power Supplies Titanium Level (96%)
7. Broadcom® 3816 Controller
Extra Specifications for Supermicro SSG-620P-ACR16L Storage DP 2U Barebone Dual 3rd Gen Intel Xeon Scalable processors Up to 4TB RDIMM/LRDIMM/Intel DCPMM SATA3, SAS3, NVMe hybrid, M.2 Dual 10GbE, IPMI LAN port
| Motherboard | ||
| Motherboard | Super X12DPi-NT6 | |
| Processor | ||
| CPU | 3rd Gen Intel® Xeon® Scalable processors | |
| Dual Socket P+ (LGA-4189) | ||
| Support CPU TDP 120-270W | ||
| Cores | Up to 38C/76T; Up to 57MB Cache | |
| System Memory | ||
| Memory | Memory Capacity: 16 DIMM slots | |
| Memory Type: 3200MHz ECC DDR4 RDIMM;LRDIMM;DCPMM | ||
| Up to 4TB: 16x 256 GB DRAM | ||
| Note | 2 extra DIMM slots available for Intel® Optane™ DCPMM @ 2666MHz | |
| Memory Voltage | 1.2 V | |
| Error Detection | ECC | |
| On-Board Devices | ||
| Chipset | Intel® C621A | |
| Network Connectivity | 2x 10GbE BaseT with Intel® X550 | |
| IPMI | Support for Intelligent Platform Management Interface v.2.0 | |
| IPMI 2.0 with virtual media over LAN and KVM-over-LAN support | ||
| Input / Output | ||
| LAN | 1 RJ45 Dedicated IPMI LAN port | |
| 2 RJ-45 10Gbase-T ports | ||
| USB | 4 USB 3.0 port(s) (4 Rear_USB) | |
| Video | 1 VGA port(s) | |
| Serial Port | 1 COM Port(s) (1 rear) | |
| DOM | 2 Super DOM (Disk on Module) port | |
| System BIOS | ||
| BIOS Type | AMI 128MB SPI Flash EEPROM | |
| Management | ||
| Software | Watch Dog | |
| NMI | ||
| SuperDoctor® 5 | ||
| IPMI 2.0 | ||
| SUM | ||
| Power Configurations | Power-on mode for AC power recovery | |
| ACPI Power Management | ||
| PC Health Monitoring | ||
| CPU | Monitors for CPU Cores, Chipset Voltages, Memory | |
| 4+1 Phase-switching voltage regulator | ||
| FAN | Status monitor for speed control | |
| Pulse Width Modulated (PWM) fan connectors | ||
| Fans with tachometer monitoring | ||
| Temperature | Monitoring for CPU and chassis environment | |
| Thermal Control for fan connectors | ||
| Chassis | ||
| Form Factor | 2U | |
| Model | CSE-829HE1C4-R1K62LPB | |
| Dimensions and Weight | ||
| Height | 3.5" (89mm) | |
| Width | 17.2" (437mm) | |
| Depth | 27.75" (705mm) | |
| Package | 10.8" (H) x 25.9" (W) x 39.3" (D) | |
| Weight | Gross Weight: 62 lbs (28.12 kg) | |
| Net Weight: 41.5 lbs (18.82 kg) | ||
| Available Color | Black | |
| Front Panel | ||
| Buttons | Power On/Off | |
| LEDs | HDD activity | |
| Power status | ||
| Network activity | ||
| System information (overheat/UID) | ||
| Expansion Slots | ||
| Note | PCIe slot 1 is occupied by the Storage Controller | |
| PCI-Express (PCIe) | 4 PCIe 4.0 x16 LP slot(s) | |
| 1 PCIe 4.0 x8 LP slot(s) | ||
| Drive Bays / Storage | ||
| Hot-swap | 16x 3.5" hot-swap SATA3/SAS3 drive bays (4x 3.5" NVMe hybrid) | |
| M.2 | 1 M.2 NVMe | |
| System Cooling | ||
| Fans | 4 Heavy Duty 8cm Fan(s) | |
| Power Supply | ||
| Dimension (W x H x L) | 73.5 x 40 x 203 mm | |
| AC Input | 1000W: 100-127Vac / 50-60Hz | |
| 1600W: 200-240Vac / 50-60Hz | ||
| +12V | Max: 83A / Min: 0A (100Vac-127Vac) | |
| Max: 133A / Min: 0A (200Vac-240Vac) | ||
| 12V SB | Max: 2.1A / Min: 0A | |
| Output Type | Gold Finger Connector | |
| Certification | Titanium Level | |
| Operating Environment | ||
| RoHS | RoHS Compliant | |
| Environmental Spec. | Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) | |
| Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) | ||
| Operating Relative Humidity: 8% to 90% (Non-Condensing) | ||
| Non-operating Relative Humidity: 5% to 95% (Non-Condensing) | ||
| Product SKUs | ||
| Product SKUs | SSG-620P-ACR16L | |
| Name | Part Number | Qty. | Description | |
|---|---|---|---|---|
| Motherboard / Chassis | MBD-X12DPi-NT6 | 1 | Super X12DPi-NT6 Motherboard | |
| Motherboard / Chassis | CSE-829HE1C4-R1K62LPB | 1 | 2U Chassis | |
| *Rail Set | MCP-290-00053-0N-01 | 1 | 36"; Rail set for Auto-latch, quick/quick, 2, 3U 17.2";W |
Note:
• Parts with * are inside the chassis
• Excessive parts might not be shipped, including but not limited to excessive drive trays, fans, riser brackets, air shrouds, IO shields, cables.....etc.
| Name | Part Number | Price | Add to Cart | Qty. | Description | |
|---|---|---|---|---|---|---|
| Bezel | MCP-210-82601-0B • | 0 | Black Front Bezel for 826 chassis | |||
| Converter Tray | MCP-220-00043-0N • | 0 | Black hot-swap gen 4 3.5 to 2.5 HDD tray | |||
| IPASS Cable | CBL-SAST-0388L-02 • | 0 | 30AWG Ipass to 4SATA 90/90/70/70CM W/ 90CM SB | |||
| Network Cards | AOC-S25G-M2S | $ 206.50 | 0 | Standard LP, 2x 25GbE SFP28, Mellanox ConnectX-4 LX EN | ||
| Network Cards | AOC-S40G-I2Q | $ 381.00 | 0 | Standard LP 2-port 40GbE controller, Intel Fortville XL710 | ||
| Network Cards | AOC-SGP-I2 • | 0 | Standard LP 2-port GbE, Intel 82575 | |||
| Network Cards | More | 0 | AOC Compatibility Matrix (Select Storage & Generation) | |||
| NVMe Support | CBL-SAST-1248-85 | $ 41.00 | 2 | [NR] Slimline x8 (LE) to Slimline x8 (STR),46CM,85 OHM,RoHS | ||
| NVMe Support | MCP-220-00116-0B • | 4 | Black gen-5.5 tool-less 3.5-to-2.5 NVME converter drive tray,RoHS/REACH | |||
| Power Cord | CBL-PWCD-0300-IS | $ 20.50 | 0 | PWCD,US,IEC60320 C14 TO C13,6FT,18AWG,RoHS/REACH | ||
| Power Cord | CBL-PWCD-0579 | $ 23.50 | 0 | Power Cord Type IEC (C14 to C13) 6 ft (14AWG), 15A, 250V | ||
| Power Cord | CBL-PWCD-0579-1 | $ 23.50 | 0 | Power Cord Type IEC (C14 to C13) 6 ft (14AWG), 15A, 250V | ||
| Rear 3808 SAS Support | AOC-S3808L-L8IT-O • | 1 | 3808 SAS Controller | |||
| Rear 3808 SAS Support | CBL-SAST-1270-100 | 1 | SlimSASx8 STR SFF-8654 to 8xSATA 7-pin,70CM,100 Ohm,RoHS | |||
| Rear 3908 SAS Support | AOC-S3908L-H8IR-16DD-O | 1 | 3908 SAS Controller | |||
| Rear 3908 SAS Support | CBL-SAST-1270-100 | 1 | SlimSASx8 STR SFF-8654 to 8xSATA 7-pin,70CM,100 Ohm,RoHS | |||
| Toolless Converter Tray | MCP-220-00118-0B • | 0 | Black gen-5.5 tool-less 3.5-to-2.5 converter drive tray,RoHS/REACH | |||
| TPM | AOM-TPM-9670V-O • | 1 | TPM 2.0, vertical form factor, provisioned for server | |||
| TPM | AOM-TPM-9671V-O | 1 | TPM 1.2, vertical form factor, provisioned for server |
| Warranty: | 3 years labor, 1 year parts, 1 year advance replacement (doa) |
| Coverage: | Replacement or repair |
| Average Service Time: | Overnight replacement for 1 year, 2 weeks afterward |
