Supermicro AOM-S3616-S 16-Port SAS3 & SATA3 & M.2 Gen3 PCIe x16 HBA Mezzanine

Supermicro AOM-S3616-S 16-Port SAS3 & SATA3 & M.2 Gen3 PCIe x16 HBA Mezzanine

  • Supports 3.5" hot-swap drives

  • SAS and SATA backplane compatibility

  • Tool-less drive access for easy servicing

  • Designed for Supermicro storage server platforms

Storage Controller Broadcom 3616 IT Mode controller, with two 3616, two M.2 connector, PCI switch, RoHS - For RMA/Serviceable 60/90 Bay Systems

$ 1,072.00$ 1,072.001072.0USD

$ 1,072.00

Option not available

PreOrder
1 lb

Contact us for volume discounts

    This combination does not exist.

    Add to Cart

    The AOM-S3616-S is a Supermicro storage expansion module designed for high-density enterprise storage systems supporting hot-swap 3.5 inch drives. It provides scalable storage capacity, efficient airflow integration, and simplified maintenance for data-intensive server environments.

    Extra Specifications for Supermicro AOM-S3616-S 16-Port SAS3 & SATA3 & M.2 Gen3 PCIe x16 HBA Mezzanine

    Main Specifications
    Device TypeBroadcom SAS3 3616 controller
    InterfacePCI-E x16
    PCI Specification RevisionPCIe 3.1
    Dimensions (WxDxH)11.547 x 3.15 in (L x W)
    Power
    Power Consumption76.6 W fully loaded
    Expansion / Connectivity
    Interface / Ports16 internal SAS3 (each controller)
    1G network controller for heartbeat functionality
    Two NVME M.2 connectors (supports 80mm and 110mm form factors)
    Storage Controller
    Data Transfer RateSAS 12 Gb/s and SATA 6 Gb/s (transfer rates and backward compatible)
    Miscellaneous
    Compatible ServersSSG-6049SP-E1CR60 X11 Single Node 60-bay, SSG-6049SP-DE1CR60 X11 Dual Node 60-bay, SSG-6049SP-DE2CR60 X11 Dual Node SBB, SSG-6049SP-E1CR90 X11 Single Node 90-bay, SSG-6049SP-DE1CR90 X11 Dual Node 90-bay, SSG-6049SP-DE2CR90 X11 Dual Node SBB 90-bay

    Warranty:3 years, 120 days advance replacement (doa)
    Coverage:Replacement or repair
    Average Service Time:Overnight replacement for 120 days, 2 weeks afterward
    E-mail:returnservices@wiredzone.com

    If you need Technical Support for this item please contact:

    Provider:Supermicro
    Type of Support:FULL
    Phone No.:408-503-8000
    URL:Click here for Manufacturer Website
