- Supermicro SYS-220HE-TNRD IoT Server 2U Barebone Dual Intel Xeon Scalable Processors 3rd Generation
Supermicro SYS-220HE-TNRD IoT Server 2U Barebone Dual Intel Xeon Scalable Processors 3rd Generation
• 5G Core and Edge
• Telecom Micro Data Center
• AI Inference and Machine Learning
• Network Function Virtualization
• Cloud Computing
Barebone 2U Rackmount SuperServer, Supports Dual Socket P+ (LGA-4189), Supporting Intel Xeon Scalable Processors 3rd Generation. Up to 8TB in 32 DIMM slots, L/RDIMM, Intel Optane Persistent Memory, Intel C621A, On-Board: Controller SATA3 (6Gbps), RAID 0/1/5/10, NVMe, RAID 0/1/5/10 Support (Intel VROC RAID Key required), 6x 2.5in Hot-swap NVMe/SATA Drive Bays (6x 2.5in NVMe hybrid), M-Key: 2280/22110, Network Connectivity: Via AIOM, 1300W DC Power Supply - (SYS-220HE-TNRD + X12DHM-6)
1. Dual Socket P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable Processors
2. 32 DIMM Slots; Up to 8TB DRAM; Up to 8TB Intel® Optane™ Persistent Memory (up to 12TB with DRAM); 3200/2933/2666 ECC DDR4 LRDIMM;RDIMM; Intel® Optane™ Persistent Memory 200 series
3. 3 PCIe 4.0 x16 slots with GPU/Accelerator support (Default); 1 PCIe 4.0 x16 expansion slots (Optional)
4. Flexible networking options with 2 AIOM networking slots (OCP NIC 3.0 compatible)
5. Up to 6x 2.5" hot-swap drive bays with options to support NVMe/SATA drives
6. 6 heavy duty hot-swap fans with optimal fan speed control Rear I/O, tool-less design
7. 1300W DC power supplies
Extra Specifications for Supermicro SYS-220HE-TNRD IoT Server 2U Barebone Dual Intel Xeon Scalable Processors 3rd Generation
| Motherboard | ||
| Motherboard | Super X12DHM-6 | |
| Processor | ||
| CPU | 3rd Gen Intel® Xeon® Scalable processors | |
| Support CPU TDP 270W | ||
| Dual Socket P+ (LGA-4189) | ||
| System Memory | ||
| Memory | Memory Type: 3200MHz ECC DDR4 RDIMM/LRDIMM | |
| Memory Capacity: 32 DIMM slots | ||
| Up to 8TB: 32x 256 GB DRAM | ||
| Memory Voltage | 1.2 V | |
| Error Detection | ECC | |
| On-Board Devices | ||
| Chipset | Intel® C621A | |
| Network Connectivity | Via AIOM | |
| IPMI | Support for Intelligent Platform Management Interface v.2.0 | |
| IPMI 2.0 with virtual media over LAN and KVM-over-LAN support | ||
| SATA | SATA3 (6Gbps); RAID 0/1/5/10 support | |
| NVMe | NVMe; RAID 0/1/5/10 support (Intel® VROC RAID Key required) | |
| Chassis | ||
| Form Factor | 2U Rackmount | |
| Model | CSE-HE211-R000NFP | |
| Note | Standard sliding rail kit: Post to Post 19.1" ~ 26.4“ | |
| Dimensions and Weight | ||
| Height | 3.5" (88.9mm) | |
| Width | 17.2" (436.88mm) | |
| Depth | 22.6" (574mm) | |
| Package | 9.7" (H) x 23.5" (W) x 36.9" (D) | |
| Weight | Net Weight: 34.4 lbs (15.6 kg) | |
| Gross Weight: 47.4 lbs (21.5 kg) | ||
| Available Color | Silver | |
| Front Panel | ||
| Buttons | Power On/Off | |
| LEDs | LAN1 activity | |
| System information | ||
| LAN2 activity | ||
| Expansion Slots | ||
| Note | If Slot 1 is configured as PCIe x16, Slot 2 will be disabled; If Slot 3 is configured as PCIe x16, Slot 4 will be disabled; If Slot 5 is configured as PCIe x16, Slot 6 will be disabled; (Optional) If Slot 7 is configured as PCIe x16, Slot 8 will be disabled. | |
| PCI-Express (PCIe) | 3 PCIe 4.0 x16 or x8 FHFL slot(s) | |
| 1 PCIe 4.0 x8 FHFL slot(s) | ||
| 2 PCIe 4.0 x8FHFL slot(s) | ||
| 1 PCIe 4.0 x8 or (Optional) x16 FHHL slot(s) | ||
| 1 PCIe 4.0 x8 FHHL or slot(s) | ||
| Drive Bays / Storage | ||
| Hot-swap | 6x 2.5" hot-swap NVMe/SATA drive bays (6x 2.5" NVMe hybrid) | |
| M.2 | M-Key, 2280/22110 | |
| 2 M.2 NVMe OR 2 M.2 SATA3 | ||
| System Cooling | ||
| Fans | 6 Hot-swappable 60x60x56mm Fan(s) | |
| Power Supply | ||
| Dimension (W x H x L) | 73.5 x 40 x 203 mm | |
| Certification | ||
| Operating Environment | ||
| Environmental Spec. | Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) | |
| Operating Relative Humidity: 8% to 90% (non-condensing) | ||
| Non-operating Relative Humidity: 5% to 95% (non-condensing) | ||
| Operating Temperature: 5°C ~ 35°C (41°F ~ 95°F) | ||
| Product SKUs | ||
| Product SKUs | SYS-220HE-TNRD | |
| Input / Output | ||
| LAN | 1 RJ45 Dedicated BMC LAN port | |
| USB | 2 USB 2.0 port(s) (2 front) | |
| Video | 1 VGA port(s) | |
| Management | ||
| Software | Watch Dog | |
| NMI | ||
| KVM with dedicated LAN | ||
| Redfish API | ||
| SuperDoctor® 5 | ||
| Intel® Node Manager | ||
| IPMI 2.0 | ||
| SUM | ||
| SSM | ||
| SPM | ||
| Power Configurations | Power-on mode for AC power recovery | |
| ACPI Power Management | ||
| PC Health Monitoring | ||
| CPU | Monitors for CPU Cores, Chipset Voltages, Memory | |
| FAN | Status monitor for speed control | |
| Pulse Width Modulated (PWM) fan connectors | ||
| Fans with tachometer monitoring | ||
| Temperature | Monitoring for CPU and chassis environment | |
| Thermal Control for fan connectors | ||
| Name | Part Number | Price | Add to Cart | Qty. | Description | |
|---|---|---|---|---|---|---|
| 6 Drive Bay Configuration (6 SAS/SATA) | AOC-S3808L-L8IT-O • + CBL-SAST-1273LP-100 | 1 | 6 SAS/SATA (HBA/IT Mode) via Broadcom 3808 for drive bays 0-5 | |||
| 6 Drive Bay Configuration (6 SAS/SATA) | AOC-S3908L-H8IR-16DD-O • + CBL-SAST-1273LP-100 | 1 | 6 SAS/SATA (HW RAID) via Broadcom 3908 (RAID 0, 1, 5, 6, 10, 50, 60) for drive bays 0-5 | |||
| Cable Management Arm for Hyper-E | MCP-290-00168-0N • | 1 | Cable Management Arm for Hyper-E | |||
| CacheVault SuperCap | BTR-CVPM05 • | 1 | CacheVault Flash Cache Protection Module for Broadcom 3916/3908 RAID controller (CVPM05) | |||
| CacheVault SuperCap to PCIe Card Bracket | BKT-BBU-BRACKET-05 | $ 82.50 | 1 | CacheVault Flash Cache Protection Module for Broadcom 3916/3908 RAID controller (CVPM05) | ||
| Optional Hyper-E RSC for slot 5 & 7 for 2 PCIe 4.0 x16 | RSC-H2-668G4S | 1 | Hyper-E RSC for slot 5 & 7 for 2 PCIe 4.0 x16 | |||
| Optional RSC and GPU AUX power cable for A40, A100 GPU | CBL-PWEX-1172-2654 • | 1,2,3 | RSC and GPU AUX power cable for A40, A100 GPU | |||
| Optional RSC and GPU AUX power cable: PCIe Auxiliary 6 pin or 8 pin for RTX GPU, Intel N3000, Xilinx U200 | CBL-PWEX-1171-2654 • | 1,2,3 | RSC and GPU AUX power cable: PCIe Auxiliary 6 pin or 8 pin for RTX GPU, Intel N3000, Xilinx U200 | |||
| Optional sliding rail kit | MCP-290-11902-0N • | 1 | Optional sliding rail kit for Post to Post: 24" ~ 35.3" | |||
| Optional sliding rail kit | MCP-290-11901-0N • | 1 | Optional sliding rail kit for Post to Post: 26.5" ~ 41.2" | |||
| Optional sliding rail kit | MCP-290-11903-0N • | 1 | 30.5" ball-bearing rail set, without auto latch for Hyper 1U & 2U Project | |||
| Slim AIOM module | AOC-A25G-i2SM | 1 | AIOM 2-Port 25GbE SFP28, based Intel E810-XXVAM2 w/ 0.5U height bracket,RoHS | |||
| Slim AIOM module | AOC-A100G-b2CM | 1 | AIOM Dual Port 100GbE QSFP28, based on Broadcom BCM57508 with 0.5U Bracket,RoHS | |||
| Slim AIOM module | AOC-AG-i4SM | 1 | AIOM 4-port GbE SFP, Intel i350-AM4 with 0.5U bracket,RoHS | |||
| Slim AIOM module | AOC-A25G-m2SM | 1 | AIOM 2-port 25GbE SFP28, Mellanox CX-6 LX w/ 0.5U height bracket,RoHS | |||
| Slim AIOM module | AOC-ATGC-i2TM | 1 | AIOM 2-port 10GBase-T RJ45, based on Intel Carlsville X710-AT2, w/ 0.5U BKT,RoHS | |||
| Slim AIOM module | AOC-A100G-m2CM | 1 | AIOM 2-port 100GbE QSFP28, Mellanox CX-6 DX w/ 0.5U bracket,RoHS | |||
| Slim AIOM module | AOC-AH25G-m2S2TM | 1 | AIOM Dual-Port 25GbE SFP28 based on Mellanox CX-4 Lx EN, and Dual-Port 10GbeE RJ45 based on Intel X550-AT2 with 0.5U Bracket, RoHS | |||
| Slim AIOM module | AOC-A25G-b2SM | 1 | AIOM 2-port 25GbE SFP28, Broadcom BCM57414 with 0.5U bracket,RoHS | |||
| Slim AIOM module | AOC-ATG-i4SM | 1 | AIOM Quad-Port 10GbE SFP+, based on Intel XL710-BM1 with 0.5U Bracket,RoHS | |||
| Slim AIOM module | AOC-ATG-i2SM | 1 | AIOM Dual-Port 10GbE SFP+, based on X710-BM2 with 0.5U Bracket,RoHS | |||
| Slim AIOM module | AOC-ATG-i2TM | 1 | AIOM 2-port 10GBase-T, Intel X550,RoHS | |||
| Slim AIOM module | AOC-AG-i4M | 1 | AIOM Quad-Port 1GbE RJ45, based on i350-AM4 with 0.5U Bracket, RoHS | |||
| Slim AIOM module | AOC-AG-i2M | 1 | AIOM Dual-Port 1GbE RJ45, based on i350-AM2 with 0.5U Bracket, RoHS | |||
| TPM security module | AOM-TPM-9671V-O | 1 | SPI capable TPM 1.2 with Infineon 9671 controller with vertical form factor | |||
| TPM security module | AOM-TPM-9670V-O • | 1 | SPI capable TPM 2.0 with Infineon 9670 controller with vertical form factor |
