| Main Specifications |
| Device Type | SuperChassis |
| Form Factor | Mid-Tower chassis |
| Supported Motherboards | E-ATX (12 "x 13"), ATX (12 "x 10") & Micro-ATX (9.6 "x 9.6") |
| Dimensions (WxDxH) | Height 16.7 "(424 mm) x Width 7.6 "(193 mm) x Depth 20.68 "(525 mm) |
| Weight | Gross Weight 30 lbs (13.61 kg) - Net Weight 27 lbs (12.25 kg) |
| Enclosure Color | Black |
| Processor |
| Compatible Processors | Dual and Single Intel and AMD processors |
| Expansion / Connectivity |
| Expansion Slots Total (Free) | 7x Full-height, Full-length Expansion Slots |
| Expansion Bays Total (Free) | 4x 3.5" fixed drive bay, Optional 4x 2.5" fixed drive bay |
| Peripheral Bay (Free) | 2x standard 5.25 "drive bay, 1x card reader module |
| Front Panel |
| Buttons | Power On / Off button |
| LEDs | HDD activity LED, 1 Network activity LEDs, System Information LED |
| I/O Ports | 2x USB 3.0 Port, 1x Audio Jack |
| Front Bezel | 1x MCP-210-73102-0B |
| System Cooling |
| Fans | 1x 12cm rear exhaust fan, Optional 1x 12cm (front) cooling fan |
| Power Supply |
| Power Supply | 1200W PS2 Multi-output power supply |
| Certification | 80PLUS Platinum Certified |
| Regulatory (Power Supply) |
| Power Supply Safety / EMC | BSMI, CCC, CE / EMC, FCC class B, UL / CB |
| Environmental |
| Operating Environment | Operating Relative Humidity Range: 8% - 90% (non-condensing) |
| Non-Operating Relative Humidity Range: 5% - 95% (non-condensing) |
| Operating Temperature Range: 5 ° C --35 ° C (41 ° F --95 ° F) |
| Non-Operating Temperature Range: -40 ° C --70 ° C (-40 ° F --158 ° F) |
| Parts List - (Items Included) |
| Cable(s) | 1x CBL-0071L, 1x CBL-0084L, 1x CBL-0453L, 1x CBL-0455L, 1x CBL-PWCD-0160-IS |
| Parts | 1x MCP-290-73101-0B, 7x MCP-120-00116-0N, 1x FAN-0124L4 |
| Drive Trays | 4x MCP-220-73101-0B |
| Mounting Rails | 1x MCP-290-73102-0N |
| Power Supply Number | 1x PWS-1K26P-PQ |
