Supermicro CSE-515M-R601 1U Rackmount 600W Power Supply

Support Proprietary WIO Motherboards
Front I/O short depth resource optimized chassis
Features two slots for SAS3 and SAS/SATA drives
Equipped with 600W Redundant power supply Platinum Level

1U Rackmount 600W Redundant Platinum Power Supply, Optimized for WIO motherboards size 8" x 110", support single Intel / AMD processors, Includes: 2x 2.5in fixed drive bay with bracket, 2x Full-height AOC expansion slot, (CSE-515M-R601)

1. Front I/O short depth resource optimized chassis
2. Support Proprietary WIO MB size up to 8"x10"
3. 600W Redundant DC power supplies Platinum Level Certified
4. 2x 2.5" Internal Drive Bays
5. Up to 2x Full-height AOC expansion slot
6. Up to 5x 40x56mm high-efficiency fans, hot-swappable
7. Support Service Tag for system information

Extra Specifications for Supermicro CSE-515M-R601 1U Rackmount 600W Power Supply

Regulatory (Power Supply)
Power Supply Safety / EMC	CCC
	CE/EMC
	FCC class A
	UL/CUL
	UL/CB
Product SKUs
Product SKUs	CSE-515M-R601
Form Factor
Form Factor	Support Proprietary WIO MB size up to 8"x10"
Processor Support
Processor Support	Single Intel® and AMD processors
Dimensions
Height	1.7" (43 mm)
Width	17.2" (437 mm)
Depth	15.7" (399 mm)
Gross Weight	18 lbs (8.16 kg)
Packaging (W x H x L)	27" (686 mm) x 8" (203 mm) x 24" (610 mm)
Available Color	Black
Expansion Slots
Expansion Slots	Up to 2x Full-height expansion slot(s)
Drive Bays
Drive Bays	Up to 2x 2.5" fixed drive bay with bracket
Front Panel
Button	Power On/Off button
	System Reset button
LED	Power status LED
	HDD activity LED
	2 Network Activity LEDs
	Fan Fail/System Over Heat LED
Systems Cooling
Fans	5x 40x56mm counter-rotation PWM fan(s)
Operating Environment (System)
Operating Temperature Range	5°C - 35°C (41°F - 95°F)
Non-Operating Temperature Range	-40°C - 70°C (-40°F - 158°F)
Operating Relative Humidity Range	8% - 90% (non-condensing)
Non Operating Relative Humidity Range	5% - 95% (non-condensing)
Power Supply
Power Efficiency	92%
Total Output Power and Input	600W with Input -44 - -65Vdc
Dimensions (L x W x H)	220 x 54.5 x 40 mm
Output Type	Backplanes (gold finger)
+12V	Max: 50A / Min: 0A (-44Vdc - -65Vdc)
+5Vsb	Max: 3A / Min: 0A
Power Distributor	PDB-PT515M-2424
	O/P: 12V/65
	+5V Max: 17A
	+3.3V Max: 13A
	-12V Max: 0A
Certification	Typical 90%+

Warranty:	3 years
Coverage:	Replacement or repair
Average Service Time:	Overnight replacement for 120 days, 2 weeks afterward
E-mail:	returnservices@wiredzone.com

If you need Technical Support for this item please contact:
Provider:	Supermicro
Type of Support:	FULL
Phone No.:	408-503-8000
URL:	Click here for Manufacturer Website

Supermicro CSE-515M-R601 1U Rackmount 600W Power Supply

$ 1,130.00$ 1,130.001130.0USD

$ 1,130.00
