- Supermicro AOC-ATG-I2SM Network Adapter 2-Port AIOM 10GbE SFP+
Supermicro AOC-ATG-I2SM Network Adapter 2-Port AIOM 10GbE SFP+
Dual 10Gbps ports with SFP+ connectors
Advanced I/O Module (AIOM) Form Factor
Network Virtualization: VXLAN and NVGRE
Supports both Direct Attach Copper and Fiber Cables
Network Adapter 2-Port AIOM 10GbE SFP+, X710-BM2 with 0.5U bracket
The Supermicro Advanced I/O Module (AIOM) is the latest form factor designed to provide a wide range of networking options as well as other I/O technologies. The 10GbE adapter AOC-ATG-i2SM is a flexible and scalable 10GbE solution providing 2 SFP+ ports. Based on Intel X710-BM2 network controller with performance-enhancing features and power management technologies, the AOC-ATG-i2SM provides a quality networking choice for data centers while reducing CPU utilization and power consumption. With the added NC-SI feature, this adapter also can function as a secure networking port for server remote management.
Advanced I/O Module (AIOM) Form Factor
2x 10Gbps ports with SFP+ connectors
Intel X710-BM2 Ethernet Controller
Network Virtualization: VXLAN and NVGRE
Intel Ethernet Flow Director
Data Plane Developer Kit for efficient packet processing (DPDK)
Asset Management Features
NC-SI for Remote Management
Supports both Direct Attach Copper and Fiber Cables
Extra Specifications for Supermicro AOC-ATG-I2SM Network Adapter 2-Port AIOM 10GbE SFP+
| Main Specifications | ||
| Device Type | Network adapter - 2 ports | |
| Interface | PCI Express 3.0 x8 | |
| Form Factor | Advanced I/O Module (AIOM) | |
| Dimensions (WxDxH) | PCB dimensions: 76mm x 115mm (W x D) | |
| Networking | ||
| Controller Type | Intel X710-BM2 | |
| Data Transfer Rate | 10 Gbps | |
| Ports | 2x SFP+ | |
| Virtualization Features | Virtual Machine Devices queues (VMDq), Single-Root I/O Virtualization (SR-IOV), VLAN, VXLAN and NVGRE, GENEVE | |
| Management Features | Asset Management support with thermal sensor, NC-SI for remote management, PXE remote boot, iSCSI remote boot | |
| Expansion / Connectivity | ||
| Expansion / Connectivity | 2x SFP+ connectors with speed up to 10Gbps per port | |
| Power | ||
| Power Consumption | ACPI compliant power management, PCI Express Active State Power Management (ASPM), Energy Efficient Ethernet (IEEE 802.3az) | |
| Software / System Requirements | ||
| OS Support | Windows Server, Linux RHEL, Linux SLES, Linux Ubuntu, Linux CentOS, FreeBSD, VMware | |
| Environmental | ||
| Operating Environment | Storage humidity: 90% non-condensing relative humidity at 35°C | |
| Storage condition: -40°C to 70°C (-40°F to 158°F) | ||
| Miscellaneous | ||
| Bracket Included | 1x BKT-0172L | |
| Compliant Standards | RoHS Compliant 6/6 | |
| Warranty: | 3 years labor, 1 year parts, 120 days advanced replacement (doa) |
| Provider: | Supermicro |
| Phone No.: | 305-640-0300 |
| E-mail: | returnservices@wiredzone.com |
| URL: | Click here for Manufacturer Website |
| Coverage: | Replacement or repair |
| Average Service Time: | Overnight replacement for 120 days, 2 weeks afterward |
