| Main Specifications |
| Device Type | MicroBlade Switch |
| Type | Broadcom BCM56846 10GbE Low Latency Switch |
| Form Factor | 3U / 6U |
| Dimensions (WxDxH) | 267 x 159 x 36 mm (10.5x6.25x1.4) |
| Weight | 3.2lbs/1.5kg |
| Performance |
| Switching Capacity | 1280Gbps |
| Networking |
| Physical Layer Features | Jumbo frames up to 9KB, 40G QSFP+ optical/copper, 10G SFP+ optical/copper, 1G RJ45 optical/copper |
| Layer Support | Layer 3 Features: BGP, OSPF, VRRP |
| Layer 2 Features: 4K VLANS, Spanning Tree (802.1D), Rapid Spanning Tree (802.1w), Multiple Spanning Trees (802.1s), IEEE 802.lQ VLANs/ port-based VLANs, IEEE 802.3ad with LACP, IEEE 802.1AB Link Layer Discovery Protocol (LLDP) |
| Advanced Layer 2 Features: Storm control, Flow control, Port mirroring, MLAG |
| System Management | Industry Standard CLI, Command Completion, Context Sensitive Help, SNMP v1/v2/v3, SSH, Syslog, DHCP (Client), Web-based management interface, NTP, RMON |
| Security Features |
| Security Features | Switch access password protection, RADIUS and TACACS+ Authentication, Access Control Lists, SSH, SSL Encryption, DHCP Snooping |
| Multicast |
| Multicast | IGMP Snooping |
| Expansion / Connectivity |
| Expansion / Connectivity | 2x 40G, 4x 10G, and 1x 1G uplinks |
| 20x 10/1Gbps downlinks (SuperBlade) |
| 56x 10/1Gbps downlinks (MicroBlade) |
| 1 Console port |
| 1 USB port |
