| Main Specifications |
| Device Type | SuperChassis |
| Form Factor | 4U chassis |
| Supported Motherboards | SMCI Proprietary WIO motherboards; max. motherboard size - 12" x 13", 13" x 13.68", Support up to 12"x13" MB with rear 2.5" HDD option installed |
| Dimensions (WxDxH) | Height 7" (178 mm) x Width 17.2" (437 mm) x Depth 27.5" (699 mm) |
| Weight | 91 lbs (41.28 kg) |
| Enclosure Color | Black |
| Processor Support |
| Processor Support | Dual and Single Intel and AMD processors |
| Expansion / Connectivity |
| Expansion Slots Total (Free) | WIO Slots 3x Low-profile expansion slot, WIO Slots 4x Full-height, Full-length expansion slot |
| Expansion Bays Total (Free) | 36x 3.5" hot-swap drive bay, Optional 2x 2.5" hot-swap drive bay |
| Peripheral Bay (Free) | Optional 4x 2.5" internal fixed drive bay, Optional 2x 3.5" internal fixed drive bay |
| Backplane |
| SAS/SATA HDD Backplane | 12-port 2U SAS3 12Gbps dual-expander backplane, support up to 12x 3.5-inch SAS3/SATA3 HDD/SSD (secondary expander port only connects to dual-port SAS devices, single-port SATA will not have this redundancy feature) |
| 24-port 4U SAS3 12Gbps dual-expander backplane, support up to 24x 3.5-inch SAS3/SATA3 HDD/SSD (secondary expander port only connects to dual-port SAS devices, single-port SATA will not have this redundancy feature) |
| Front Panel |
| Buttons | Power On/Off button, System Reset button |
| LEDs | Power status LED, HDD activity LED, 2 Network Activity LEDs, Unit Identification (UID) LED, Fan Fail/System Over Heat LED |
| System Cooling |
| Fans/Air Shroud | 7x 8cm (7000 RPM) hot-swap PWM cooling fan(s) |
| System Monitoring |
| System Monitoring | Chassis intrusion switch |
| Environmental |
| Operating Environment | Operating Temperature Range: 5°C - 35°C (41°F - 95°F) |
| Non-Operating Temperature Range: -40°C - 70°C (-40°F - 158°F) |
| Operating Relative Humidity Range: 8% - 90% (non-condensing) |
| Non-Operating Relative Humidity Range: 5% - 95% (non-condensing) |
| Power Supply |
| Power Supply | 1U 1200W/1000W Titanium Power Supply W/PMbus W76xL336xH40mm |
| Certification | 80PLUS Titanium Certified |
| Regulatory Safety / EMC | BSMI, CCC, CE/EMC, FCC class A, UL/CB, UL/CUL |
| Parts List - (Items Included) |
| Air Shroud | 1x MCP-310-49004-0N |
| Backplane | 1x BPN-SAS3-826EL2, 1x BPN-SAS3-846EL2 |
| Fan(s) | 7x FAN-0126L4, 7x FAN-0204L4 |
| Front Panel Control | 1x MCP-280-82601-0N |
| Drive Trays | 36x MCP-220-00075-0B, 1x MCP-220-84709-ASM |
| Mounting Rails | 1set MCP-290-00057-0N, 1x MCP-410-00007-0N |
| Cable(s) | 1x CBL-0071L, 2x CBL-0160L, 1x CBL-0217L |
| Power Distributor(s) | 1x PDB-PT847-8824 |
| Power Supply Number | 2x PWS-1K23A-1R |
| Parts | 1x MCP-230-84705-0N, 1x MCP-290-00095-0N, 1x MCP-290-82606-0N, 1x MCP-290-84603-0N, 1x MCP-290-84607-0V |
