| Main Specifications |
| Device Type | SuperChassis |
| Form Factor | Mini 1U chassis |
| Supported Motherboards | Flex-ATX (9"x7.5") & Mini-ITX (6.7"x6.7") MB |
| Dimensions (WxDxH) | Height 1.7" (43 mm) x Width 17.2" (437 mm) x Depth 9.8" (249 mm) |
| Weight | Gross Weight 14.5 lbs (6.58 kg) - Net Weight 4.73 lbs (2.15 kg) |
| Enclosure Color | Black |
| Processor |
| Compatible Processors | Single Intel Xeon processors, up to 65W |
| Expansion / Connectivity |
| Expansion Slots Total (Free) | Up to 1x Full-height, Half-length expansion slot(s) (Riser Card Required, See 'Drive Bays' for possible configurations) |
| Expansion Bays Total (Free) | Up to 2x 2.5" hot-swap SAS3/SATA drive bay, Or optional 4x 2.5" Internal drive bay |
| Or optional 1x 3.5" Internal drive bay, Or optional 1x 2.5" Internal drive bay with 1 Full-height, Half-length PCI |
| Only SAS or enterprise SATA HDD recommended |
| Backplane |
| SAS/SATA HDD Backplane | 2-Port 2U SAS3 12Gbps backplane, support up to 2x 2.5-inch SAS3/SATA3 HDD/SSD |
| Front Panel |
| Buttons | Power On/Off button, System Reset button |
| LEDs | HDD activity LED, System Information LED, Power Fail LED, 2 Network Activity LEDs, Power LED |
| System Cooling |
| Fans/Air Shroud | 1x High-efficiency power supply with thermal control fan |
| 3x 40x28mm PWM fan(s) (Fan PN: FAN-0065L4 / 13K RPM fan. 2 for system cooling, 1 for PCIe card cooling) |
| System Monitoring |
| System Monitoring | Optional Chassis intrusion switch |
| Environmental |
| Operating Environment | Operating Temperature Range: 5°C - 35°C (41°F - 95°F) |
| Non-Operating Temperature Range: -40°C - 70°C (-40°F - 158°F) |
| Operating Relative Humidity Range: 8% - 90% (non-condensing) |
| Non-Operating Relative Humidity Range: 5% - 95% (non-condensing) |
| Power Supply |
| Power Supply | 300W Redundant module cable Power supply |
| Certification | 80 PLUS Gold |
| Regulatory Safety / EMC | CCC, CE/EMC, FCC class A, UL/CB, UL/CUL |
| Parts List - (Items Included) |
| Backplane | 1x BPN-SAS3-826TQ-B2B |
| Front Panel Control | 1x FPB-FP826-D, 1x FPB-TB826 |
| Drive Tray(s) | 2x MCP-220-00147-0B |
| Cable(s) | 2x CBL-PWCD-0260-IS, 1x CBL-PWEX-1097-15, 1x CBL-PWEX-1098F-10 |
| Power Distributor(s) | 1x PDB-PT506-N24 |
| Power Supply Number | 2x PWS-301P-1R |
| Parts | 1x MCP-220-82618-0B, 1x MCP-230-50601-0B, 1x MCP-240-50601-0B, 1x MCP-270-50601-0B, 2x MCP-290-50401-0B, 1x MCP-290-50601-0B, 1x MCP-120-00116-0B, 3x MCP-320-81302-0B, 1x MCP-260-00100-0B |
