| Main Specifications |
| Device Type | SuperChassis |
| Form Factor | Mid-Tower chassis |
| Supported Motherboards | Support for motherboard size ATX 12" x 10", Micro ATX 9.6" x 9.6", E. ATX 12" x 13" |
| Dimensions (WxDxH) | Height 16.7" (424 mm) x Width 7.6" (193 mm) x Depth 20.68" (525 mm) |
| Weight | Gross Weight 30 lbs (13.61 kg) - Net Weight 28 lbs (12.7 kg) |
| Enclosure Color | Black |
| Expansion / Connectivity |
| Expansion Slots Total (Free) | 7x Full-height, Full-length Expansion Slots |
| Expansion Bays Total (Free) | 4x 3.5" fixed drive bay, Optional 4x 2.5" fixed drive bay |
| Peripheral Bay (Free) | 2x standard 5.25" drive bay, 1x 3.5" internal fixed drive bay, 1x 90 degree rotatable drive cage |
| Front Panel |
| Buttons | Power On/Off button |
| LEDs | Power status LED, HDD activity LED, 1 Network activity LEDs, System Overheat LED |
| Front Bezel | 1x MCP-210-73201-0B |
| Storage Controller |
| Support | 2x USB 3.0 Port |
| System Cooling |
| Fans/Air Shroud | 1x 12cm rear exhaust fan, Optional 1x 12cm (front) cooling fan |
| Environmental |
| Operating Environment | Operating Temperature Range: 5°C - 35°C (41°F - 95°F) |
| Non-Operating Temperature Range: -40°C - 70°C (-40°F - 158°F) |
| Operating Relative Humidity Range: 8% - 90% (non-condensing) |
| Non-Operating Relative Humidity Range: 5% - 95% (non-condensing) |
| Power Supply |
| Power Supply | 600W PS2 Redundant Power supply, RoHS |
| Certification | 80 PLUS Gold Certified |
| Regulatory Safety / EMC | BSMI, CCC, CE/EMC, FCC class B, TUV/CB, UL/CUL |
| Miscellaneous |
| Bracket | 1x MCP-250-73201-0N |
| Parts List |
| Cables | 1x CBL-0071L, 1x CBL-0084L, 1x CBL-CUSB-1007 |
| Parts List - (Items Included) |
| Parts | 7x MCP-120-00116-0N, 1x MCP-230-73201-0N |
| Fan(s) | 1x FAN-0124L4 |
| Front Panel Control | 1x MCP-280-73101-0B |
| Drive Trays | 4x MCP-220-73101-0B |
| Power Supply Number | 1x PWS-603R-PQ |
