| Main Specifications |
| Device Type | SuperChassis |
| Form Factor | 1U Chassis |
| Supported Motherboards | Support WIO/Proprietary motherboard size up to 12.3" x 13" |
| Dimensions (WxDxH) | Height 1.7" (43 mm) x Width 17.2" (437 mm) x Depth 25.6" (650 mm) |
| Weight | 36 lbs (16.33 kg) |
| Enclosure Color | Black |
| Processor |
| Compatible Processors | Dual and Single Intel and AMD processors |
| Expansion / Connectivity |
| Expansion Slots Total (Free) | 1x Low-profile expansion slot, 2x Full-height, Full-length expansion slot |
| Expansion Bays Total (Free) | 4x 3.5" hot-swap SAS3/SATA drive bay, SAS or enterprise SATA HDD only recommended |
| Peripheral Bay (Free) | Optional 1x slim DVD-ROM drive bay |
| Backplane |
| SAS/SATA HDD Backplane | 4-Port 1U SAS3 12Gbps Hybrid backplane, support up to 4x 3.5-inch SAS3/SATA3/NVMe Storage Devices |
| Front Panel |
| Buttons | Power On/Off button, System Reset Button, Unit Identification (UID) button |
| LEDs | Power status LED, HDD activity LED, 2 Network Activity LEDs, Unit Identification (UID) LED, Fan Fail/System Over Heat LED |
| System Cooling |
| Fans/Air Shroud | 4x 40x56mm counter-rotation PWM fan, Optional 2x fans for AOC cooling |
| Environmental |
| Operating Environment | Operating Temperature Range: 5°C - 35°C (41°F - 95°F) |
| Non-Operating Temperature Range: -40°C - 70°C (-40°F - 158°F) |
| Operating Relative Humidity Range: 8% - 90% (non-condensing) |
| Non-Operating Relative Humidity Range: 5% - 95% (non-condensing) |
| Power Supply |
| Power Supply | 1U 600W platinum efficiency multiple output power supply w/PMBus |
| Certification | 80PLUS Platinum Certified |
| Regulatory Safety / EMC | BSMI, CCC, CE/EMC, FCC class B, TUV/CB, UL/CUL |
| Parts List - (Items Included) |
| Air Shroud | 1x MCP-310-19001-0N |
| Hard Drive Backplane | 1x BPN-SAS3-815TQ-N4 |
| Front Panel Control | 1x FPB-FP815U |
| Fan Holders | 1x CSE-PT0135 |
| Drive Tray(s) | 4x MCP-220-00075-0B |
| Mounting Rails | 1set MCP-290-00054-0N |
| Rear Window | 1x MCP-240-00097-0N |
| Cable(s) | 1x CBL-0335L, 1x CBL-PWCD-0160-IS |
| Power Supply Number | 1x PWS-605P-1H |
| Fan(s) | 1x FAN-0141L4, 4x FAN-0141L4, 4x FAN-0163L4 |
| Parts | 1x MCP-290-00173-0N, 1x MCP-230-00036-0N, 1x MCP-240-00099-0N, 1x MCP-270-81503-0N, 1x CSE-PT93L-B, 2x MCP-340-00035-0B, 1x MCP-120-00030-0N, 2x MCP-120-00053-0N |
