Supermicro CSE-847BE1C4-R1K23LPB4 4U Rackmount 1200W/1000W Power supply

Offers 36x hot-swap 3.5" SAS/SATA hard drive bays
Equipped with 1200W/1000W Titanium Power Supply W/PMbus
Chassis accepts motherboard size: 12" x 10", 13.68" x 13", 9.6" x 9.6"
Includes seven slots, 7x hot-plug 80mm fans, system status LED indicators

4U Rackmount 1200W/1000W Redundant Titanium Certified W/PMbus Power Supply, Optimized for motherboards sizes 12" x 10", 13.68" x 13", 9.6" x 9.6", support single and dual Intel / AMD processors, Includes: 36x 3.5in hot-swap SAS/SATA drive bay, Optional 4x 2.5in/2x 3.5in internal fixed drive bay, 7x Low Profile Expansion Slots (CSE-847BE1C4-R1K23LPB4)

The CSE-847BE1C4-R1K23LPB4 designs provide high-density storage in a 4U form factor, with high power efficiency, optimized HDD signal trace routing, and improved HDD carrier design to dampen vibration and maximize performance. Equipped with a 1200W/1000W Titanium Level) high-efficiency redundant power supply and seven hot-plug redundant cooling fans, the CSE-847BE1C4-R1K23LPB4 is reliable, high-quality storage workhorse system.

Key Features

4U Chassis for motherboard support size: (12" x 10") (13.68" x 13") (9.6" x 9.6")
36 x 3.5" hot-swap SAS/SATA drive bay with SES3, optional 2 x 2.5" hot-swap drive bay
12-Port 2U Backplane with Expander support up to 8 x 3.5" SAS3/SATA3 HDD/SDD and 4 x SAS3/SATA3/NVMe Storage Devices,HF,RoHS/REACH
24-port 4U SAS3 12Gbps single-expander backplane, support up to 24x 3.5-inch SAS3/SATA3 HDD/SSD
1U 1200W/1000W Titanium Power Supply W/PMbus W76xL336xH40mm
7 low-profile expansion slot(s)
7 x 80mm high-performance fan(s)

Extra Specifications for Supermicro CSE-847BE1C4-R1K23LPB4 4U Rackmount 1200W/1000W Power supply

Main Specifications
Device Type	SuperChassis
Form Factor	4U chassis
Supported Motherboards	Motherboard support size of 12" x 10", 13.68" x 13", 9.6" x 9.6"
Dimensions (WxDxH)	Height 7" (178 mm) x Width 17.2" (437 mm) x Depth 27.5" (699 mm)
Weight	91 lbs (41.28 kg)
Enclosure Color	Black
Processor Support
Processor Support	Dual and Single Intel and AMD processors
Expansion / Connectivity
Expansion Slots Total (Free)	7x low-profile expansion slots
Expansion Bays Total (Free)	36x 3.5" hot-swap SAS/SATA drive bay with SES3 , Optional 2x 2.5" hot-swap drive bay
Peripheral Bay (Free)	Optional 4x 2.5" internal fixed drive bay, Optional 2x 3.5" internal fixed drive bay
Front Panel
Buttons	Power On/Off button, System Reset button
LEDs	Power status LED, HDD activity LED, 2 Network Activity LEDs, Unit Identification (UID) LED, Fan Fail/System Over Heat LED
System Cooling
Fans/Air Shroud	7x 80mm high-performance fan
System Monitoring
System Monitoring	Chassis intrusion switch
Environmental
Operating Environment	Operating Temperature Range: 5°C - 35°C (41°F - 95°F)
	Non-Operating Temperature Range: -40°C - 70°C (-40°F - 158°F)
	Operating Relative Humidity Range: 8% - 90% (non-condensing)
	Non-Operating Relative Humidity Range: 5% - 95% (non-condensing)
Power Supply
Power Supply	1U 1200W/1000W Titanium Power Supply W/PMbus W76xL336xH40mm
Certification	80PLUS Titanium Certified
Regulatory Safety / EMC	BSMI, CCC, CE/EMC, FCC class A, UL/CB, UL/CUL
Parts List - (Items Included)
Air Shroud	1x MCP-310-49004-0N
Hard Drive Backplane	1x BPN-SAS3-826EL1-N4, 1x BPN-SAS3-846EL1
Front Panel Control	1x FPB-TB826-T
Drive Trays	36x MCP-220-00075-0B, 1x MCP-220-84708-ASM
Mounting Rails	1x MCP-410-00007-0N, 1set MCP-290-00057-0N
Power Distributor(s)	1x PDB-PT847-8824
Power Supply Number	2x PWS-1K23A-1R
Cable(s)	1x CBL-0071L, 2x CBL-0160L, 7x CBL-PWEX-1079
Parts	7x MCP-120-00115-0N, 1x MCP-230-84705-0N, 1x MCP-270-84703-0N, 1x MCP-290-00095-0N, 1x MCP-290-84606-0V, 1x MCP-290-84615-0V

Warranty:	3 years
Coverage:	Replacement or repair
Average Service Time:	Overnight replacement for 120 days, 2 weeks afterward
