| System Memory |
| DIMM Sizes | 1GB, 2GB, 4GB, 8GB |
| Error Detection | Corrects single-bit errors |
| Detects double-bit errors (using ECC memory) |
| Memory Capacity | Up to 32GB Unbuffered ECC/non-ECC UDIMM, DDR3-1600MHz, in 4 DIMM slots |
| Memory Voltage | 1.35V, 1.5V |
| Memory Type | 1600MHz ECC/non-ECC DDR3 SDRAM 72-bit, 240-pin gold-plated DIMMs |
| On-Board Devices |
| Chipset | Intel® C226 Express PCH |
| Network Controllers | Single LAN with Intel® Ethernet Controller I210-AT Single LAN with Intel® Ethernet Controller I217LM |
| SATA | SATA3 via PCH w/ RAID 0, 1, 5, 10 |
| SATA3 via ASM1061® |
| Audio | RealTek ALC1150 HD Audio |
| Graphics | for E3-1275 v3* only |
| Input / Output |
| LAN | 2 RJ45 Gigabit Ethernet LAN ports |
| Others | 2x Type B 1394a headers, PS/2 connector for mouse and keyboard |
| USB | 10 USB 2.0 ports (4 rear + 6 via headers) |
| 6 USB 3.2 Gen1 ports (2 rear + 4 via headers) |
| Video Output | 1 VGA port, 1 DVI - I port, 1 DP (DisplayPort) port, 1 HDMI port, |
| for E3-1275 v3* only |
| Serial Port / Header | 2 COM Ports (2 headers) |
| TPM | TPM Header |
| System BIOS |
| BIOS Features | ACPI 5.0 |
| USB Keyboard support |
| DMI (SMBIOS) 2.7 |
| BIOS Type | 128Mb SPI Flash EEPROM with AMI BIOS |
| Product SKUs |
| Product SKUs | - Discontinued SKU (EOL). Please contact sales-rep for replacement SKUs. |
| Physical Stats |
| Form Factor | ATX |
| Dimensions | 12" x 9.6" (30.48cm x 24.38cm) |
| Processor/Cache |
| CPU | Intel® Xeon® processor E3-1200 v3, Intel® Xeon® Processor E3-1200 v4 series |
| Single Socket LGA-1150 (Socket H3) supported, CPU TDP supports Up to 95W TDP |
| A Graphic Integrated CPU is required to have the on-board video functioned. Examples: E3-1265L v3, E3-1275 v3 |
| Expansion Slots |
| PCI-E | 2 PCI-E 3.0 x16 slots (16/NA or 8/8) |
| 3 PCI-E 2.0 x1 |
| 2 - 5V PCI 32bit |
| Management |
| Software | AMT, SuperDoctor® III, vPro, Watchdog |
| Power Configurations | Main Switch Override Mechanism |
| Power-on mode for AC power recovery |
| ACPI Power Management |
| Internal/External modem ring-on |
| PC Health Monitoring |
| Voltage | +1.8V, +12V, +3.3V, +5V, +5V standby, 5 (4-pin), 5 Phase-switching voltage regulator with auto-sense from 0.8375V-1.60V, HT, VBAT |
| Temperature | Monitoring for CPU and chassis environment, CPU thermal trip support, Thermal Monitor 2 (TM2) support, PECI, FC temperature sensing logic |
| LED | CPU / System Overheat LED, +5V Standby alert LED |
| Other Features | Chassis intrusion detection, Chassis intrusion header |
| Operating Environment |
| Operating Temperature Range | 0°C ~ 50°C (32°F ~ 122°F) |
