- Supermicro PWS-1K05A-1R Redundant Hot-swappable Power Supply 1000W
Supermicro PWS-1K05A-1R Redundant Hot-swappable Power Supply 1000W
80 Plus Certification Titanium power supply
Supplying 1000W output power at 91% efficiency
Hot-swap replacement to eliminate system downtime
Mean-time between failure of greater than 200,000 hours
Power Supply Redundant Hot-swappable, 800W / 1000W Design for Supermicro server 80 Plus Titanium RoHS and REACH compliant
The Supermicro PWS-1K05A-1R is an 80 Plus Titanium power supply capable of supplying 1000W output power at 91% efficiency. Enjoy the simplicity of active power factor correction (PFC) and automatically correct AC input for a full range of voltages. Features a card edge connector for connection with the backplane of compatible Supermicro 1U systems. This power supply is designed to not only provide you reliable power to your Supermicro server but also protects it from over voltage, over current and short circuiting via protective circuitry embedded into the unit. Rest easy knowing your hardware will be up and running with a mean-time between failure (MTBF) of greater than 200,000 hours and an LED indicator to keep you informed on normal/abnormal conditions for your PSU. This power supply is redundant to safe-guard your system from power failure and allows for hot-swap replacement to eliminate system downtime. All materials contained comply with RoHS requirements and is certified by Supermicro.
Extra Specifications for Supermicro PWS-1K05A-1R Redundant Hot-swappable Power Supply 1000W
Main Specifications | ||
Device Type | Power supply | |
Type | Module | |
Form Factor | 1U Chassis | |
Dimensions (WxDxH) | 38 x 40 x 360 mm | |
Output Type | Gold Finger (FCI 16P14S) | |
Power Device | ||
Power Provided | 800W / 1000W | |
Input Voltage Range | 100-127V, 200-240V | |
5V standby | 4A | |
80 PLUS Certification | 80 Plus Titanium | |
Power Supply | ||
AC Input Frequency | 50-60Hz | |
+5V | N/A | |
+12V | 66.7/83A | |
+3.3V | N/A | |
Power Efficiency | ||
Energy Efficient | 91% Peak | |
Miscellaneous | ||
Compatible Servers | SYS-1028TP-DC0FR, SYS-1028TP-DC0R, SYS-1028TP-DC0TR, SYS-1028TP-DC1FR, SYS-1028TP-DC1R, SYS-1028TP-DC1TR, SYS-1028TP-DTFR, SYS-1028TP-DTR, SYS-1028TP-DTTR, SYS-1029TP-DC0R, SYS-1029TP-DC1R, SYS-1029TP-DTR, SYS-2028R-TXR, SYS-2029P-TXRT | |
Compatible Chassis | CSE-213XAC-R1K05LP | |
Features | Enjoy the simplicity of active power factor correction (PFC) and automatically correct AC input for a full range of voltages |
Warranty: | 3 years, 120 days advance replacement (doa) |
Coverage: | Replacement or repair |
Average Service Time: | Overnight replacement for 120 days, 2 weeks afterward |
E-mail: | returnservices@wiredzone.com |
If you need Technical Support for this item please contact: | |
Provider: | Supermicro |
Type of Support: | FULL |
Phone No.: | 408-503-8000 |
URL: | Click here for Manufacturer Website |
