Supermicro SYS-210SE-31D IoT Server 2U Barebone Single Intel Xeon Scalable Processors 3rd Generation
• Multi-Access Edge Computing
• Flex-RAN, Open-RAN vBBU
• Telecom DRAN, CRAN, and Edge Core Application
• Enterprise Edge Computing
Barebone 2U Rackmount SuperServer, Three Nodes, Each Node Supports: Single Socket P+ (LGA-4189), Supporting Intel Xeon Scalable Processors 3rd Generation (Up to 32C/64T, Up to 48MB Cache) Supports 85W - 270W TDP CPUs (Air Cooled), Intel C621A chipset, Supports Up to 2TB DDR4-3200MHz RDIMM/LRDIMM in 8 DIMM slots, Intel Optane Persistent Memory 200 Series - 2 NVMe M.2 2280/22110, 1x 1GbE BaseT port, 1 VGA port, 1 COM Port, 1 KVM dongle, 2000W DC Redundant Power Supply - (SYS-210SE-31D + Super X12SPED-F)
1. Single Socket P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable processor (per node)
2. 8 DIMMs; Up to 2TB 3DS ECC DDR4-3200: RDIMM/LRDIMM (per node)
3. 2 PCIe Gen4 x16 FHHL slot and 1 PCIe Gen4 x16 HHHL slot (per node)
4. 2 NVMe M.2 2280/22110 (per node)
5. 4 counter-rotated fan speed control (per node); 1 Air Shroud (per node)
6. Front-access 1+1 Redundant 2000W DC Power Supplies (per system)
Extra Specifications for Supermicro SYS-210SE-31D IoT Server 2U Barebone Single Intel Xeon Scalable Processors 3rd Generation
Management | ||
Software | SuperDoctor® 5 | |
IPMI 2.0 | ||
Power Configurations | Power-on mode for AC power recovery | |
ACPI Power Management | ||
PC Health Monitoring | ||
CPU | Monitors for CPU Cores, Chipset Voltages, Memory | |
FAN | Status monitor for speed control | |
Pulse Width Modulated (PWM) fan connectors | ||
Fans with tachometer monitoring | ||
Temperature | Monitoring for CPU and chassis environment | |
CPU thermal trip support, PEPI | ||
Front Panel | ||
Buttons | UID button | |
Power On/Off | ||
LEDs | Power status | |
LAN1 activity | ||
System information | ||
Motherboard | ||
Motherboard | Super X12SPED-F | |
Processor (per Node) | ||
CPU | 3rd Gen Intel® Xeon® Scalable processors | |
Single Socket P+ (LGA-4189) | ||
Support CPU TDP 85-270W | ||
Please contact Supermicro Technical Support for supporting conditions of high power (TDP >205W) processors. | ||
Cores | Up to 32C/64T; Up to 48MB Cache | |
System Memory (per Node) | ||
Memory | Memory Capacity: 8 DIMM slots | |
Memory Type: 3200MHz ECC DDR4 RDIMM/LRDIMM | ||
Memory Voltage | 1.2 V | |
Error Detection | ECC | |
On-Board Devices (per Node) | ||
Chipset | Intel® C621A | |
Network Connectivity | 1x 1GbE BaseT port(s) | |
IPMI | Support for Intelligent Platform Management Interface v.2.0 | |
IPMI 2.0 with virtual media over LAN and KVM-over-LAN support | ||
Input / Output (per Node) | ||
LAN | 1 RJ45 GbE LAN port (Shared NIC | |
Video | 1 VGA port(s) | |
Serial Port | 1 COM Port(s) (1 COM) | |
Others | 1 KVM dongle (output VGA x1, COM x1, USB 2.0 x2 through KVM cable) | |
Chassis | ||
Form Factor | 2U Rackmount | |
Model | CSE-SE201-R2K06P | |
Note | 16.9” (430mm) chassis depth | |
Front access IO design, and tool less serviceability | ||
Three front hot-swappable nodes with single CPU socket and 8 DIMM design | ||
Dimensions and Weight | ||
Height | 3.5" (88mm) | |
Width | 17.7" (449mm) | |
Depth | 16.9" (430mm) | |
Package | 9.5" (H) x 29.5" (W) x 23.2" (D) | |
Weight | Net Weight: 55.1 lbs (25 kg) | |
Gross Weight: 70.6 lbs (32 kg) | ||
Available Color | Silver | |
Drive Bays / Storage (per Node) | ||
Drive Bays | N/A | |
M.2 | 2 M.2 NVMe | |
M-Key, 2280/22110 | ||
System Cooling | ||
Air Shroud | 3 Air Shroud(s) Air Shroud(s) | |
Power Supply | ||
Total Output Power | 2000W : (-44) - (-60) Vdc | |
Dimension (W x H x L) | 73.5 x 40 x 265 mm | |
+12V | Max: 166.6A | |
12V SB | Max: 4A | |
Certification | ||
Operating Environment | ||
Environmental Spec. | Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) | |
Operating Relative Humidity: 8% to 90% (non-condensing) | ||
Non-operating Relative Humidity: 5% to 95% (non-condensing) | ||
Operating Temperature: 0°C ~ 35°C (32°F ~ 95°F) | ||
Note | Operating Temperature (CPU TDP up to 270W) : Continuous0°C to 35°C (32°F to 95°F) | |
Operating Temperature(CPU TDP up to 205W): Continuous 0°C ~ 35°C (32°F ~ 95°F), Short term -5°C ~ 55°C (23°F ~ 131°F) | ||
Product SKUs | ||
Product SKUs | SYS-210SE-31D | |
Expansion Slots (per Node) | ||
PCI-Express (PCIe) | 1 PCIe 5.0 x16 LP slot(s) | |
2 PCIe 4.0 x16 FHHL slot(s) |
Name | Part Number | Qty. | Description | |
---|---|---|---|---|
Motherboard / Chassis | MBD-X12SPED-F | 3 | Super X12SPED-F Motherboard | |
Motherboard / Chassis | CSE-SE201-R2K06P | 1 | 2U Chassis | |
Add-on Card / Module | AOM-BPN-SE3N-P | 1 | Backplane for SuperEdge 2U3N,RoHS | |
Cable | CBL-0218L | 1 | 11.5CM KVM/SUVI 36PIN TO 9PIN/15PIN/2USB | |
Cable | CBL-PWEX-1058 | 2 | 48VDC input power cable for PWS-2K03D-1R, 4M, 8AWG,RoHS | |
Riser Card | RSC-W-66G4 | 3 | 1U LHS WIO Riser card with two PCIe 4.0 x16 slots,HF,RoHS | |
Riser Card | RSC-WR-6 | 3 | 1U RHS WIO Riser card with one PCIe 4.0 x16 slot,HF,RoHS | |
Software | SFT-OOB-LIC | 3 | License key for enabling OOB BIOS management | |
Heatsink / Retention | SNK-P0077V | 3 | X12 ICX/CPX CPU Heatsink (78x113x25.5mm), VC Base, Cu Fin | |
*Power Supply | PWS-2K06F-1R | 2 | 2000W 1U -48Vdc single output Redundancy power supply | |
*Power Distributor | PDB-PT201-DSG | 2 | Super Edge pass through board support Ultra powers up to 6KW |
Note:
• Parts with * are inside the chassis
• Excessive parts might not be shipped, including but not limited to excessive drive trays, fans, riser brackets, air shrouds, IO shields, cables.....etc.
Name | Part Number | Price | Add to Cart | Qty. | Description | |
---|---|---|---|---|---|---|
Optional sliding rail kit | MCP-290-00144-1N | $ 92.50 | 0 | 2U fixed rail set, quick release, default for 2,3U 17.6"W, 26.5"-33.5" D | ||
TPM security module | AOM-TPM-9670V | $ 56.50 | 0 | SPI capable TPM 2.0 with Infineon 9670 controller with vertical form factor |
