- Supermicro A1SRM-2558F Motherboard mATX Intel Atom C2558, System-on-Chip, up to 64GB DDR3, SATA, Quad Gigabit LAN, VGA
Supermicro A1SRM-2558F Motherboard mATX Intel Atom C2558, System-on-Chip, up to 64GB DDR3, SATA, Quad Gigabit LAN, VGA
Motherboard mATX Intel Atom C2558, System-on-Chip - Supports up to 64GB DDR3 1600MHz (4x 240-pin DDR3 DIMM Socket) - On-board : SoC SATA-600 / SATA-300 Controller, C2000 SoC 1354 Quad Gigabit LAN, IPMI, VGA - MBD-A1SRM-2558F
1. Intel® Atom® Processor C2558 Single Socket FCBGA-1283 supported, CPU TDP support Up to 15W TDP
2. System on Chip
3. 64GB Unbuffered ECC/non-ECC UDIMM, DDR3-1600MHz, in 4 DIMM slots , all 4 slots must use identical DIMM with x8 only
4. 1 PCI-E 2.0 x8 1 PCI-E 2.0 x4
5. 1 port
6. SoC controller for 4 SATA2 (3 Gbps) ports; 2 SATA3 (6 Gbps)
7. Quad LAN with Intel® C2000 SoC I354
Extra Specifications for Supermicro A1SRM-2558F Motherboard mATX Intel Atom C2558, System-on-Chip, up to 64GB DDR3, SATA, Quad Gigabit LAN, VGA
| On-Board Devices | ||
| Chipset | System on Chip | |
| Network Controllers | Quad LAN with Intel® C2000 SoC, I354 | |
| SATA | 2 SATA3 (6 Gbps) ports; RAID 0/1 | |
| SoC controller for 4 SATA2 (3 Gbps) ports | ||
| Graphics | 1 ASPEED AST2400 BMC port(s) | |
| System Memory | ||
| DIMM Sizes | N/A | |
| Memory Capacity | 4 DIMM slots | |
| 64GB Unbuffered ECC/non-ECC UDIMM, DDR3-1600MHz | ||
| Memory Voltage | N/A | |
| Memory Type | N/A | |
| Input / Output | ||
| Others | 1 Support one SMC SATA DOM | |
| USB | 7 USB 2.0 port(s) (2 via header; 1 Type A; 4 rear) | |
| Video Output | 1 port(s) | |
| Serial Port | 2 COM Port(s) (1 header; 1 rear) | |
| 2 fast UART 16550 Serial | ||
| TPM | 1 TPM Header | |
| System BIOS | ||
| BIOS Type | 128MB UEFI | |
| Product SKUs | ||
| Product SKUs | MBD-A1SRM-2558F | |
| Physical Stats | ||
| Form Factor | mATX | |
| Dimension | N/A | |
| Processor | ||
| CPU | Intel® Atom® Processor C2558 | |
| Single Socket FCBGA-1283 supported, CPU TDP supports Up to 15W TDP | ||
| Expansion Slots | ||
| PCIe | 1 PCIe 2.0 x8 | |
| 1 PCIe 2.0 x4 | ||
| Management | ||
| Software | SuperDoctor® 5, NMI, IPMI2.0 , Watchdog | |
| PC Health Monitoring | ||
| Voltage | System level control, Supports system management utility, Chassis intrusion header, +5V standby, +5V, +3.3V, +12V, +1.8V | |
| FAN | Fan speed control | |
| PWM fan speed control | ||
| System level control | ||
| Thermal control tachometer fan connectors | ||
| Overheat LED indication | ||
| 3x 4-pin fan headers (up to 3 fans) | ||
| Other Features | WOL, UID, System level control, CPU thermal trip support for processor protection, Control of power-on for recovery from AC power loss, ATX Power connector, ACPI power management, Intel® QuickAssist Technology | |
| Warranty: | 3 years labor, 1 year parts, 120 days advance replacement (doa) |
