| Product SKUs |
| Product SKUs |
| Switch Module |
| MBM-XEM-002+ | Broadcom BCM56846 10GbE Low Latency Switch |
| 2x 40G, 4x 10G, and 1x 1G uplinks |
| 56x 10/1Gbps downlinks (MicroBlade) |
| 1 Console port, 1 USB port |
| Details | See Details |
| Central Management Module (CMM) |
| MBM-CMM-FIO | CMM with Front IO support |
| Details | See Details |
| Processor (per node) |
| CPU | Single Socket H5 (LGA 1200), CPU TDP support up to 95W |
| Support Intel® Xeon® processor E-2300 series |
| Cores | Up to 8 cores, 16 threads |
| System Memory (per node) |
| Memory Capacity | 4 DDR4 DIMM sockets |
| Supports up to 128GB DDR4 ECC VLP UDIMM |
| Memory Type | 3200MHz ECC DDR4 UDIMM |
| DIMM Sizes | 32GB |
| Memory Voltage | 1.2 V |
| Error Detection | Corrects single-bit errors |
| Detects double-bit errors (using ECC memory) |
| On-Board Devices (per node) |
| Chipset | Intel® C256 chipset |
| Network Controllers | Dual 10GbE LAN ports |
| IPMI | Support for Intelligent Platform Management Interface (IPMI) v.2.0 via Chassis Management Module (CMM) |
| System BIOS |
| BIOS Type | 128Mb Flash EEPROM |
| BIOS Features | SMBIOS 2.7.1 |
| Plug and Play (PnP) |
| APM 1.2 |
| Dimensions |
| Height | 5.215" (132.5mm) |
| Width | 17.67" (449mm) |
| Depth | 36.10" (917mm) |
| Weight | Gross Weight: 139.20 lbs (63.14 kg) |
| Available Colors | Silver Grey |
| Front Panel |
| LEDs | Power LED |
| UID / KVM LED |
| Network Activity LED |
| Fault LED |
| Drive Bays (per node) |
| Internal | 2x 2.5" U.2 NVMe (7mm) drives |
| M.2 | M.2 Key: M-Key |
| M.2 Interface: 1 PCI-E 3.0 x4 |
| M.2 Form Factor: 2280/22110 |
| Others | 1x SATA DOM |
| Input / Output |
| TPM | 1 TPM Header |
| Operating Environment / Compliance |
| Environmental Spec. | Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) |
| Operating Relative Humidity: 8% to 90% (non-condensing) |
| Non-operating Relative Humidity: 5% to 95% (non-condensing) |
| Operating Temperature: 10°C to 38°C (50°F to 100.4°F) |
| Electromagnetic Compatibility (EMC) |
| United States / Canada | FCC- Emissions (US) Verification |
| Europe | EN55022 - Emissions |
| EN55024 - Immunity |
| EN61000-3-2 - Harmonics |
| EN61000-3-3 - Voltage Flicker |
| CE - EMC Directive 89/336/EEC |
