Easy installation and excellent cooling
Fully tested, and validated by Supermicro
Compatible with Various Supermicro Chassis
40x40x28 mm 22.5K RPM for SC813MF Chassis
Nidec (W40S12BS1D5-57T03A) FAN-0154L4 is a standard fan for CSE-113MFTS, CSE-801LTS, and CSE-813MFTS series chassis. This fan has been fully tested and validated by Supermicro to ensure the best quality and cooling performance.
| Main Specifications | ||
| Application | SC813MF | |
| Device Type | System Fan | |
| Dimensions (WxDxH) | 40 x 40 x 28 mm | |
| Rated Current (A) | 1.05 | |
| Fan | ||
| Air Flow (Total) | 28.6 | |
| Noise (dBA) | 61.0 | |
| Speed (RPM) | 22.5K RPM | |
| Static Pressure (In.H20) | 3.46 | |
| Miscellaneous | ||
| Compatible Chassis | CSE-113MFAC2-341CB, CSE-113MFAC2-605CB, CSE-113MFAC2-R606CB, CSE-113MFAC2-R608CB, CSE-113MFAC2-R804CB, CSE-513BTQC-350B, CSE-513BTQC-350WB, CSE-813MF2TQC-505CB, CSE-813MF2TQC-R608CB, CSE-813MF2TQC-R804CB, CSE-813MFTQ-R606CB, CSE-813MFTQC-350CB2, CSE-813MFTQC-505CB, CSE-813MFTQC-505CB2, CSE-813MFTQC-R407CB, CSE-813MFTQC-R608CB2 | |
| Warranty: | 3 years, 120 days advance replacement (doa) |
| Coverage: | Replacement or repair |
| Average Service Time: | Overnight replacement for 120 days, 2 weeks afterward |
| E-mail: | returnservices@wiredzone.com |
| If you need Technical Support for this item please contact: | |
| Provider: | Supermicro |
| Type of Support: | FULL |
| Phone No.: | 408-503-8000 |
| URL: | Click here for Manufacturer Website |
