| Main Specifications |
| Dimensions (WxDxH) | Width 7.6" (193 mm) x Height 16.7" (424 mm) x Depth 20.68" (525.3 mm) |
| Color | Black |
| Form Factor | Support for max. motherboard size - 12" x 13" E-ATX |
| Product Type | Mid-Tower & Workstation chassis |
| Weight | 30 lbs (13.6 kg) |
| Processor Support |
| Processor Support | Supports dual, single Intel / AMD processors |
| Expansion / Connectivity |
| Expansion Slots Total (Free) | 7x Full-height, Full-length I/O expansion slots |
| Drive Bays |
| Internal | 4x 3.5" SAS/SATA HDD Bays (90 rotatable drive cage) |
| 4x 2.5" HDD Bays (optional) |
| Hot-swap | SAS or enterprise SATA HDD only recommended |
| Peripheral Drives |
| Peripheral Bay | 2x 5.25" peripheral drive bays |
| Front Panel |
| Buttons | Power On/Off button |
| LEDs | Power LED, Hard drive activity LED, Network activity LED, System Information LED |
| Networking |
| Ports | 2x Front USB 2.0 ports |
| System Cooling |
| Fans | 1x 12cm (1850rpm) rear exhaust fan |
| 1x 12cm (1850rpm) front cooling fan (opt.) |
| Optimized Cooling Technology at 21dB Whisper-Quiet Operation |
| FAN-0124L4 |
| Operating Environment (System) |
| Operating Temperature Range | Operating Temperature Range 5C ~ 35C (41F ~ 95F) |
| Non-Operating Temperature Range -40C ~ 60C (-40F ~ 140F) |
| Operating Relative Humidity Range 8% ~ 90% (non-condensing) |
| Non-Operating Relative Humidity Range 5% - 95% (non-condensing) |
| Power Supply |
| Power Supply | 500W Redundant Power Supply (PS2) |
| PWS-503R-PQ |
| Regulatory (Power Supply) |
| Power Supply Safety / EMC | USA - UL listed, FCC, Canada - CUL listed, Germany - TUV Certified, Europe/CE Mark, EN 60950/IEC 60950-Compliant, CCC Certified |
| Parts List |
| Cables | CBL-0160L, CBL-0071L, CBL-0084L |
| Standard Parts List |
| Chassis | CSE-732i-R500B |
| Chassis Parts | MCP-280-73101-0B |
| Parts List - (Items Included) |
| Drive Trays | MCP-220-73101-0B |
