| Main Specifications |
| Device Type | SuperServer |
| Built-in Devices | Super X11SDW-14CN-TP13F+ |
| Form Factor | IP65 Enclosure - CSE-B403-IP65 |
| Dimensions (WxDxH) | Height 32.31" (821mm) x Width 12.56" (319mm) x Depth 10.16" (258mm) |
| Weight | Gross Weight: 157 lbs (71.21 kg) - Net Weight: 101.5 lbs (46.04 kg) |
| Enclosure Color | White |
| Processor |
| Embedded Processor | Intel Xeon processor D-2177NT, CPU TDP support 105W - 14 Cores, 28 Threads |
| System Memory |
| Memory Capacity | Up to 512GB DDR4 ECC LRDIMM, Up to 256GB DDR4 ECC RDIMM, 4 DIMM slots |
| Memory Type | 2666/2400/2133MHz ECC DDR4 L/RDIMM, Operating speed up to 2667MHz |
| DIMM Sizes | 128GB, 64GB, 32GB, 16GB |
| Memory Voltage | 1.2 V |
| On-Board Devices |
| Chipset | System on Chip (SoC) |
| SATA/SAS | SATA3 (6Gbps) ports via SoC controller |
| Network Controllers | 4x 10G SFP+ via SoC, 8x 1GbE with Intel I350-AM4, Single 1GbE with Intel I210 |
| IPMI | Support for Intelligent Platform Management Interface v.2.0, IPMI 2.0 with virtual media over LAN and KVM-over-LAN support |
| Graphics | VGA via Aspeed AST2500 BMC |
| Input / Output |
| SATA | 4 SATA3 (6Gbps) ports, SSD only; RAID 0, 1, 5, 10 |
| LAN | 9 RJ45 Gigabit Ethernet LAN ports, 4 10G SFP+ LAN ports, 1 RJ45 Dedicated IPMI LAN port |
| USB(s) | 2 USB 3.0 ports (front), 2 USB 2.0 ports (front) |
| Video Output | 1 VGA port |
| Serial Port / Headers | 1 COM via RJ45 |
| System BIOS |
| BIOS Type | 128Mb SPI Flash with AMI BIOS |
| Management |
| Software | Intel Node Manager, IPMI 2.0, NMI, SUM, Watch Dog, SuperDoctor 5 |
| Front Panel |
| LEDs | Thermal Sensor LED, Server Power LED, Heater Power LED, Main Power LED, Fan LED, Cabinet Intrusion LED |
| Expansion / Connectivity |
| Expansion Slots Total (Free) | 2 PCI-E 3.0 x16 (FH3/4L) slots or 2 PCI-E 3.0 x8, 1 PCI-E 3.0 x16 (FH3/4L) slots |
| M.2 | 1 M.2 M-Key , 2280/22110 |
| 1 M.2 E-Key , 2230 |
| 1 M.2 B-Key , 3042 |
| Expansion Bays Total (Free) | 4 Internal 2.5" drive bays |
| System Cooling |
| Fans/Air Shroud | 3x 80x80mm PWM redundant fans |
| Power Supply |
| Power Supply | Total Power: 900W -44 Vdc to -59 Vdc, support dual power input |
| Server Power: 600W Short depth DC48V input Redundant Power Supplies |
| Environmental |
| Operating Environment | Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) |
| Operating Relative Humidity: 8% to 90% (non-condensing) |
| Non-operating Relative Humidity: 5% to 95% (non-condensing) |
| Operating Temperature: -40°C ~ 46°C + Solar load (-40°F ~ 114.8°F + Solar load) |
| Miscellaneous |
| Environmental Compliance | RoHS Compliant |
| Parts List - (Items Included) |
| Motherboard / Chassis | 1x MBD-X11SDW-14CN-TP13F+ / CSE-E403iF-000NDBP2 |
| Add-On Card | 1x AOM-SDW-B16X2-P |
| Cable(s) | 2x CBL-0082L, 1x CBL-CDAT-0850, 1x CBL-CUSB-0831, 4x CBL-SAST-0641 |
| Fan(s) | 3x FAN-0201L4 |
| Parts | 1x MCP-260-00153-0B |
| Power Supply Number | 2x PWS-601D-1R |
| Power Distributor(s) | 1x PDB-PT403-1400 |
