| Motherboard |
| Motherboard | Super C7Z87-OCE |
| Processor/Cache |
| CPU | Single Socket H3 (LGA 1150) |
| Intel® 4th Gen Core i7/i5/i3 processors |
| System Memory |
| Memory Capacity | 4x 240-pin DDR3 DIMM slots |
| Supports up to 32GB DDR3 Non-ECC Un-Buffered memory (UDIMM) |
| Memory Type | 1600MHz non-ECC DDR3 SDRAM 72-bit, 240-pin gold-plated DIMMs |
| Support overclocking up to 2133MHz* / 2200MHz* / 2400MHz* / 2600MHz* / 2800MHz* / 3000MHz* * Please check the operation manual for supported components |
| DIMM Sizes | 8GB, 4GB, 2GB, 1GB |
| Memory Voltage | 1.5V, 1.35V |
| On-Board Devices |
| Chipset | Intel® Z87 Chipset |
| SATA | SATA3 via PCH w/ RAID 0, 1, 5, 10 |
| SATA3 via ASM1061® |
| Network Controllers | Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output |
| Intel® i217V + Intel® i210AT Controllers |
| Audio | RealTek ALC1150 High Definition Audio |
| Input / Output |
| SATA | 6x SATA3 (6Gbps) ports via PCH |
| 2x SATA3 (6Gbps) ports via ASM1061® |
| Total of 8x SATA3 ports (6Gbps) |
| LAN | 2x RJ45 Gigabit Ethernet LAN ports |
| USB | 6x USB 3.0 ports (2 front, 4 rear) |
| 4x USB 2.0 ports (2 front, 2 rear) |
| Audio | 7.1 HD Audio by Realtek ALC1150 |
| Display | 1x VGA, 1x HDMI, 1x DVI, 1x Thunderbolt (DP1.1), Triple display support |
| Serial Port / Header | 1x COM port (header) |
| Expansion Slots |
| PCI-Express | 3 (x16) PCI-E 3.0 slots - Function as: 16/NA/NA or 8/8/NA or 8/4/4 |
| 3 (x1) PCI-E 2.0 in x4 slots |
| System BIOS |
| BIOS Type | 128Mb SPI Flash EEPROM with AMI® BIOS |
| BIOS Features | ACPI 5.0 |
| USB Keyboard support |
| DMI (SMBIOS) 2.7 |
| Chassis |
| Form Factor | Mid-Tower |
| Model | CSE-732G-903B |
| Dimensions and Weight |
| Height | 20.08" (510mm) |
| Width | 8.66" (220mm) |
| Depth | 22.83" (580mm) |
| Gross Weight | 35 lbs (15.87 kg) |
| Available Colors | Black |
| Front Panel |
| Buttons | Power On/Off button |
| LEDs | Power LED |
| System Information LED |
| Hard drive activity LED |
| Network activity LED |
| Ports | 2x front USB 3.0 Ports |
| 2x front USB 2.0 Ports |
| 1x front HD/AC97 Audio Port |
| 1x eSATA Port |
| Drive Bays |
| Hot-swap | 3x 3.5" Hot-swap Internal Drive Bays |
| 2x 3.5" Hot-swap External Drive Bays |
| Optional 4x 2.5" Hot-swap External Drive Bay Cage |
| Peripheral | 2x 5.25" Peripheral Drive Bays |
| 1x 3.5" Device Bay |
| System Cooling |
| Fans | 1x 12cm rear exhaust fan |
| 1x 12cm front cooling fan |
| Power Supply |
| Power Supply | 900W AC multi output power supply |
| AC Voltage | 100-240 V, 50-60 Hz, 10-6 Amp |
| +5V Standby | 3 Amp |
| +12V1 | 25 Amp |
| +12V2 | 25 Amp |
| +12V3 | 25 Amp |
| +12V4 | 25 Amp |
| +5V | 25 Amp |
| +3.3V | 25 Amp |
| -12V | 0.5 Amp |
| Certification | Gold Level |
| Note: | • Max. continuous combined load on +3.3V and +5V output shall not exceed 155W. • Max. continuous combined load on +12V1, +12V2, +12V3 and +12V4 output shall not exceed 860W. |
| PC Health Monitoring |
| CPU | 6-Phase-switching voltage regulator |
| Monitors for CPU Cores, +1.8V, +3.3V, +5V, +12V, +3.3V Standby, +5V Standby, VBAT, Memory, Chipset Voltages. |
| FAN | Low noise fan speed control |
| Temperature | Monitoring for CPU and chassis environment |
| PECI |
| Thermal Control for 8x fan connectors |
| Operating Environment / Compliance |
| RoHS | RoHS Compliant |
| Environmental Spec. | Operating Temperature: 10°C to 35°C (50°F to 95°F) |
| Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) |
| Operating Relative Humidity: 8% to 90% (non-condensing) |
| Non-operating Relative Humidity: 5% to 95% (non-condensing) |
| Product SKUs |
| Product SKUs | SYS-5038AD-T (Black) |
