Intel Celeron Processor G6900E 3.00 GHz
Intel Quick Sync Video, Clear Video HD Technology
Dual Core, and Two Thread, 4 MB Intel Smart Cache
Ideal for Embedded Broad Market Commercial Temp
Processor 3.00GHz Celeron G6900E 2-Core (2 Threads) FCLGA1700 4 MB Intel Smart Cache 7nm Processor Base Power 46 W 1P OEM, Tray
Advanced Technologies
Intel Gaussian & Neural Accelerator 3.0
Intel Deep Learning Boost (Intel DL Boost)
Intel Speed Shift Technology
Intel 64
Instruction Set 64-bit
Instruction Set Extensions
Intel SSE4.1, Intel SSE4.2, Intel AVX2
Idle States
Enhanced Intel SpeedStep Technology
Thermal Monitoring Technologies
Intel Volume Management Device (VMD)
Security & Reliability
Intel Control-Flow Enforcement Technology
Intel AES New Instructions
Secure Key
Intel OS Guard
Execute Disable Bit
Intel Boot Guard
Mode-based Execute Control (MBEC)
Intel Virtualization Technology (VT-x)
Intel Virtualization Technology for Directed I/O (VT-d)
Intel VT-x with Extended Page Tables (EPT)
| Main Specifications | ||
| Device Type | Processor | |
| Processor Number | G6900E | |
| Clock Speed | 3.00GHz | |
| Multi-Core Technology | 2-Core | |
| Number of Threads | 2 threads | |
| Product Collection | Intel Celeron processor G Series | |
| Code Name | Products formerly Alder Lake | |
| Vertical Segment | Embedded | |
| Processor | ||
| Cache | 4 MB Intel Smart Cache | |
| Thermal | ||
| Design Power | 46 W | |
| Memory Specifications | ||
| Max Memory Size (dependent on memory type) | 128 GB | |
| Memory Types | Up to DDR5 4800 MT/s, Up to DDR4 3200 MT/s | |
| Max # of Memory Channels | 2 | |
| Max Memory Bandwidth | 76.8 GB/s | |
| ECC Memory Supported | Yes | |
| Integrated Graphics | ||
| Processor Graphics | Intel UHD Graphics 710 | |
| Base Frequency | 300 MHz | |
| Max Dynamic Frequency | 1.3 GHz | |
| Max Supported Resolution | Max Resolution (HDMI) 4096 x 2160 @ 60Hz, Max Resolution (DP) 7680 x 4320 @ 60Hz, Max Resolution (eDP - Integrated Flat Panel) 5120 x 3200 @ 120Hz | |
| Features IG | Intel Clear Video HD Technology, Intel Quick Sync Video, Quad Display Capable | |
| Expansion Options | ||
| Direct Media Interface (DMI) Revision | 4.0 | |
| Max # of DMI Lanes | 8 | |
| Scalability | 1S | |
| PCI Express Revision | 5.0 and 4.0 | |
| PCI Express Configurations | Up to 1x16+4, 2x8+4 | |
| Max # of PCI Express Lanes | 20 | |
| Package Specifications | ||
| Sockets Supported | FCLGA1700 | |
| Max CPU Configuration | 1 | |
| Thermal Solution Specification | PCG 2020C | |
| Case Temperature | 100°C | |
| Package Size | 45.0 mm x 37.5 mm | |
| Miscellaneous | ||
| Use Conditions | Embedded Broad Market Commercial Temp | |
| Package Type | OEM, Tray | |
