Main Specifications |
Device Type | Network adapter - 2 ports |
Form Factor | Plug-in Card |
Interface (Bus) Type | PCI Express 4.0 x16 |
PCI Specification Revision | PCIe 1.1, PCIe 2.0, PCIe 3.0, PCIe 4.0 |
Networking |
Port Type | 100 Gigabit QSFP56 x 2 |
Data Link Protocol | GigE, 10 GigE, 40 Gigabit LAN, 100 Gigabit Ethernet, 25 Gigabit LAN, 50 Gigabit LAN |
Data Transfer Rate | 100 Gbps |
Network / Transport Protocol | TCP/IP, UDP/IP, IPSec, SMB |
Expansion / Connectivity |
Interfaces & Connections | 2 x 100Gb Ethernet - QSFP56 |
Miscellaneous |
Features | Firewall protection, MPLS support, DoS attack prevention, firmware upgradable, Quality of Service (QoS), PXE support, Large Send Offload (LSO), Large Receive Offload (LRO), Receive Side Scaling (RSS), UEFI support, Single Root I/O Virtualization (SR-IOV), Energy Efficient Ethernet, Advanced Error Reporting (AER), checksum offload support, Extended Message-Signaled Interrupts (MSI-X), iSCSI remote boot, Ethernet remote boot, Transmit Side Scaling (TSS), RDMA over Converged Ethernet (RoCE), Network Controller Sideband Interface (NC-SI), Virtual Extensible LAN (VXLAN), Network Virtualization using Generic Routing Encapsulation (NVGRE), Link Aggregation, TLP Processing Hint (TPH), Software Defined Networking (SDN), Message Signaled Interrupts (MSI), Data Plane Development Kit (DPDK), iSCSI Extensions over RDMA (iSER), VLAN Tagging, Accelerated Switching And Packet Processing (ASAP), MCTP over SMBus, Network Function Virtualization (NFV), GENEVE support, NVMe over Fabrics (NVMe-oF) |
Compliant Standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3ap, IEEE 802.3az, IEEE 802.3ba, IEEE 802.1AX, IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 802.1Qbg, IEEE 1588v2, IEEE 802.3bj, IEEE 802.3by, IEEE 802.3cd |
Encryption Algorithm | TLS, 256-bit AES-GCM, 128-bit AES-GCM, AES-XTS |
