Supermicro SSG-136R-4MU32JBF Enterprise Optimized Storage 1U Barebone Front-loading All-flash Storage Box 32x Hot-swap 2.5in NVMe Bays and PCIe 4.0

2 RJ45 1 GbE Dedicated IPMI LAN ports
Thirty-two 2.5" NVMe SSDs in hot-swap drive carriers
Equipped with Dual 1000W Redundant Titanium Level power supply

Barebone 1U Front-loading All-flash Storage Box, Chipset: System on Chip, Network Connectivity: 2 RJ45 1 GbE Dedicated IPMI LAN Ports, Default: 32x Front Hot-swap 2.5in NVMe Drive Bays, 2 PCIe 4.0 x16 FHHL Slots, 1000W Power Supply - (CSE-136TS-R000JNP-U2 + Super BPN-NVME4-136PL-J) - SSG-136R-4MU32JBF

IPMI management with dedicated LAN
32x hot-swap U.2/U.3 NVMe drive bays
1000W Redundant Power Supplies
4 PCIe Gen4 rear IO ports, 2 PCIe Gen4 x16 slots

Extra Specifications for Supermicro SSG-136R-4MU32JBF Enterprise Optimized Storage 1U Barebone Front-loading All-flash Storage Box 32x Hot-swap 2.5in NVMe Bays and PCIe 4.0

Main Specifications
Device Type	Front-loading All-flash Storage Box
Built-in Devices	Super BPN-NVME4-136PL-J
Form Factor	1U Rackmount
Dimensions (WxDxH)	Height 1.71" (43.6 mm) x Width 17.26" (438.4 mm) x Depth 31.95" (811.7 mm)
Weight	Gross Weight: 65 lbs (29.5 kg) - Net Weight: 49 lbs (22.2 kg)
Enclosure Color	Silver
Processor/Chipset
Chipset	System on Chip
On-Board Devices
Network Connectivity	2 RJ45 1GbE with Realtek
Management
Software	SuperCloud Composer, Supermicro Server Manager (SSM), Supermicro Update Manager (SUM), SuperDoctor 5, Super Diagnostics Offline, TAS: Supermicro Thin-Agent Service (TAS), SAA(new!)
Power Configurations	Power-on mode for AC power recovery, ACPI Power Management
Front Panel
LEDs	Network activity, Power status, System information (overheat/UID)
Buttons	Power On/Off button
Expansion / Connectivity
Expansion Slots Total (Free)	2 PCIe 4.0 x16 FHHL slot(s)
Expansion Bays Total (Free)	32 front hot-swap 2.5" NVMe drive bay(s)
System Cooling
Fans/Air Shroud	8 Heavy Duty 4cm Fan(s)
Power Supply
Power Supply	1x 1000W Redundant Titanium Level power supply
Parts List - (Items Included)
Motherboard / Chassis	1x MBD-BPN-NVME4-136PL-J /1x CSE-136TS-R000JNP-U2
Backplane	2x BPN-NVME4-136NB-L, 2x BPN-NVME4-136NB-R, 2x BPN-NVME4-136PL, 1x BPN-NVME4-136PL-J
Cable(s)	4x CBL-SAST-1012, 4x CBL-OTHR-1042, 2x CBL-PWCD-0579
Riser Cards	2x RSC-XR-6G4
Fan(s)	8x FAN-0188L4
Drive Trays	32x MCP-220-00149-06
Rail Set	1x MCP-290-11809-0N
Power Supply Number	2x PWS-1K04A-1R

Warranty:	3 years labor, 1 year parts, 1 year advance replacement (doa)
Coverage:	Replacement or repair
Average Service Time:	Overnight replacement for 1 year, 2 weeks afterward
E-mail:	returnservices@wiredzone.com

If you need Technical Support for this item please contact:
Provider:	Supermicro
Type of Support:	FULL
Phone No.:	408-503-8000
URL:	Click here for Manufacturer Website

Supermicro SSG-136R-4MU32JBF Enterprise Optimized Storage 1U Barebone Front-loading All-flash Storage Box 32x Hot-swap 2.5in NVMe Bays and PCIe 4.0

$ 6,259.00$ 6,259.006259.0USD

$ 6,259.00
