Provides Dual SFP28 Connectors
Support for 25GbE and 10GbE Speed
Mellanox ConnectX-6 Lx 25GbE Controller
25GbE Deployments in Cloud, Telco, Enterprise Data Centers
25Gb Ethernet Adapter Card, Based on the Mellanox ConnectX-6 Lx 25GbE Controller, Provides Dual SFP28 port, Support for 25GbE and 10GbE Speed, Asset Management Features with Thermal Sensor, 1U Height Bracket Included - (AOC-A25G-M2S-O)
Supermicro 2-port 25Gb Network Adapter
The AOC-A25G-m2SM is one of the most feature-rich and low-power consumption 25GbE controllers in the market. Based on the Mellanox ConnectX-6 Lx controller with features such as VXLAN, NVGRE, RDMA, and others, it provides unparalleled density, performance, and functionality. The Supermicro AOC-A25G-M2S is the most versatile 25GbE controller in the market with the best total cost of ownership for 25GbE deployments in the cloud, telco, and enterprise data centers
Key Features
Mellanox ConnectX-6 Lx 25GbE controller
Support for 25GbE and 10GbE Speed
Dual SFP28 connectors
RDMA over Converged Ethernet
VXLAN, NVGRE, and Geneve
Asset Management Features with thermal sensor
Network Controller Sideband Interface (NC-SI) for Remote Management
| Main Specifications | ||
| Device Type | 25Gigabit Ethernet Card | |
| Interface | PCI-E x8 | |
| Form Factor | Low Profile | |
| Networking | ||
| Controller Type | Based on the Mellanox ConnectX-6 Lx 25GbE Controller | |
| Storage Accelerations | NVMe over Fabric offloads for target, Storage protocols: iSER, NFSoRDMA, SMB Direct, NVMe-oF, and more | |
| RDMA over Converged Ethernet | RoCE v1/v2, Zero-Touch RoCE: no ECN, no PFC, RoCE over overlay networks, IPsec over RoCE, Selective repeat, GPUDirect, Dynamically Connected Transport (DCT), Burst buffer offload | |
| Management and Control | SMBus 2.0, Network Controller Sideband Interface (NC-SI), NC-SI, MCTP over SMBus and MCTP over PCIe - Baseboard Management Controller interface, PLDM for Monitor and Control DSP0248, PLDM for Firmware Update DSP026 | |
| Remote Boot | Remote boot over Ethernet, Remote boot over iSCSI, UEFI support for x86 and Arm servers, PXE boot | |
| Connectivity | ||
| Connectors | Dual SFP28 ports | |
| Miscellaneous | ||
| Compliant Standards | IEEE 802.3ae 10 Gigabit Ethernet, IEEE 802.3by 25G supporting all FEC modes, IEEE 802.3ad, 802.1AX Link Aggregation, IEEE 802.3az Energy Efficient Ethernet (supports only “Fast-Wake” mode), IEEE 802.3ap based auto-negotiation and KR startup, IEEE 802.1Q, 802.1P VLAN tags and priority, IEEE 802.1Qaz (ETS), IEEE 802.1Qbb (PFC), IEEE 802.1Qbg, IEEE 1588v2, IEEE 1149.1 and IEEE 1149.6 JTAG, PCI-E 3.0 and 4.0 | |
| Environmental Compliance | Storage temperature: -40°C to 70°C (-40°F to 158°F) | |
| Storage humidity: 90% non-condensing relative humidity at 35°C | ||
| Features | Support for 25GbE and 10GbE Speed, Asset Management Features with Thermal Sensor | |
| Bracket Included | 1U height bracket | |
| Power | ||
| Power Consumption | Maximum: 15W | |
| Warranty: | 3 years labor, 1 year parts, 120 days advanced replacement (doa) |
| Provider: | Supermicro |
| Phone No.: | 305-640-0300 |
| E-mail: | returnservices@wiredzone.com |
| URL: | Click here for Manufacturer Website |
| Coverage: | Replacement or repair |
| Average Service Time: | Overnight replacement for 120 days, 2 weeks afterward |
| If you need Technical Support for this item please contact: | |
| Provider: | Supermicro |
| Type of Support: | FULL |
| Phone No.: | 408-503-8000 |
| URL: | Click here for Manufacturer Website |
