| Product SKUs |
| Product SKUs | SYS-211GT-HNTR |
| Motherboard |
| Motherboard | Super X13SET-G |
| Processor (per Node) |
| CPU | 4th Gen Intel® Xeon® Scalable processors |
| Single Socket E (LGA 4677) |
| Intel Xeon CPU Max Series with high bandwidth memory (HBM) |
| Note | CPUs with high TDP (Air Cooled) only supported under specific conditions. Contact Technical Support for details |
| Supports up to 300W TDP CPUs (Air Cooled) |
| System Memory (per Node) |
| Memory | Memory Capacity: 16 DIMM slots |
| Up to 4TB: 16x 256 GB DRAM |
| Memory Type: 4800MHz ECC DDR5 RDIMM |
| On-Board Devices (per Node) |
| Chipset | Intel® C741 |
| Network Connectivity |
| IPMI | Support for Intelligent Platform Management Interface v.2.0 |
| IPMI 2.0 with virtual media over LAN and KVM-over-LAN support |
| Input / Output (per Node) |
| LAN | 1 RJ45 Dedicated BMC LAN port |
| USB | 2 USB 3.0 port(s) (2 USB) |
| Video | 1 VGA port(s) |
| System BIOS |
| BIOS Type | AMI 32MB Flash ROM |
| Management |
| Software | SuperCloud Composer |
| Supermicro Intelligent Mgmt (BMC Resources) |
| Supermicro IPMI Utilities |
| Supermicro Diagnostics Offline (SDO) |
| Supermicro Thin-Agent Service (TAS) |
| Supermicro Power Manager (SPM) |
| Supermicro Update Manager (SUM) |
| Supermicro Server Manager (SSM) |
| Supermicro Server Mgmt (Redfish® API) |
| SuperDoctor® 5 (SD5) |
| PC Health Monitoring |
| CPU | Monitors for CPU Cores, Chipset Voltages, Memory. |
| 8+4 Phase-switching voltage regulator |
| FAN | Status monitor for speed control |
| Pulse Width Modulated (PWM) fan connectors |
| Fans with tachometer monitoring |
| Temperature | Monitoring for CPU and chassis environment |
| Chassis |
| Form Factor | 2U Rackmount |
| Model | CSE-GT214BC-R2K21BP |
| Dimensions and Weight |
| Height | 3.46" (88mm) |
| Width | 17.67" (449mm) |
| Depth | 28" (711.2mm) |
| Package | 9.76" (H) x 24.65" (W) x 45.28" (D) |
| Weight | Net Weight: 68 lbs (30.8 kg) |
| Gross Weight: 88 lbs (39.9 kg) |
| Available Color | Black front & sliver body |
| Front Panel |
| Buttons | Power On/Off button |
| UID button |
| LEDs | Network activity LEDs |
| Power status LED |
| HDD activity LED |
| Universal Information (UID) LED |
| Expansion Slots (per Node) |
| PCI-Express (PCIe) | 2 PCIe 5.0 x16 slot(s) |
| Drive Bays / Storage (per Node) |
| Hot-swap | 6x 2.5" hot-swap NVMe/SATA drive bays (6x 2.5" NVMe dedicated) |
| M.2 | 2 M.2 NVMe OR 2 M.2 SATA3 |
| System Cooling |
| Fans | 2x 16.5K RPM Heavy Duty 8cm Fan(s) |
| 2x 16K RPM Heavy Duty 8cm Fan(s) |
| Power Supply |
| Dimension (W x H x L) | 106 x 84 x 245 mm |
| AC Input | 100-127Vdc (1200W for the Rest of the World) |
| 200-220Vdc (1800W for the Rest of the World) |
| 200-220Vdc (2090W for North America - UL & cUL) |
| 220-230Vdc (1980W for the Rest of the World) |
| 220-240Vdc (2200W for North America - UL & cUL) |
| 230-240Vdc (2090W for the Rest of the World) |
| Certification | Titanium Level |
| Operating Environment |
| RoHS | RoHS Compliant |
| Environmental Spec. | Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) |
| Non-operating Temperature: -30°C to 60°C (-22°F to 140°F) |
| Operating Relative Humidity: 8% to 80% (non-condensing) |
| Non-operating Relative Humidity: 8% to 90% (non-condensing) |
