| Main Specifications |
| Device Type | SuperChassis |
| Dimensions (WxDxH) | Width: 16.8" (426mm) x Height: 1.7" (43mm) x Depth: 21.95" (558mm) |
| Color | Black |
| Form Factor | 1U chassis for motherboard support size of 12" x 13" 12" x 10" 12" x 9.6" ATX 12" x 10" E. ATX 12" x 13" Micro ATX 9.6" x 9.6" |
| Weight | 29 lbs (13.2kg) |
| Processor Support |
| Processor Support | Supports dual, single Intel / AMD processors |
| Expansion / Connectivity |
| Expansion Slots Total (Free) | 1x Full-height, Full-length AOC expansion slot |
| Peripheral Drives |
| DVD-ROM | Slim DVD-ROM drive (optional) |
| Drive Bays |
| Hot-swap | 4x Hot-swap 2.5" SAS / SATA HDD trays, SAS or enterprise SATA HDD only recommended |
| Peripheral Drives | 1x MCP-290-11101-0B |
| Front Panel |
| Buttons | Power On/Off button, System Reset button |
| LEDs | Power status LED, HDD activity LED, 2x Network activity LEDs |
| System Cooling |
| Fans | 3x 40x56mm 4-pin PWM fans |
| 2x 40x28mm 4-pin PWM fans for add-on card (optional) |
| 3x FAN-0101L4 |
| Operating Environment (System) |
| Operating Temperature Range | Operating Temperature Range: 5C ~ 35C (41F ~ 95F) |
| Non-Operating Temperature Range: -40C ~ 60C (-40F ~ 140F) |
| Operating Relative Humidity Range: 8% ~ 90% (non-condensing) |
| Non-Operating Relative Humidity Range: 5% - 95% (non-condensing) |
| Power Supply |
| Certification | 80PLUS Platinum Certified |
| Power Supply | 600W High-Efficiency Power Supply w/PMBus 1.2, I2C, PFC, and Digital Switching |
| 1x PWS-605P-1H |
| Regulatory (Power Supply) |
| Power Supply Safety / EMC | USA - UL listed, FCC, Canada - CUL listed, CCC Certification, EN 60950/IEC 60950-Compliant, Europe/CE Mark, Germany - TUV Certified |
| SAS / SATA Backplane |
| SAS / SATA Backplane | 1U 2.5" SAS / SATA HDD backplane |
| Standard Parts List |
| Accessory | 1x MCP-260-00024-0N |
| Chassis | 1x CSE-111TQ-600CB |
| Front Panel | 1x FPB-FP1U-D |
| Rear Window | 1x MCP-240-11102-0N |
| Parts List - (Items Included) |
| Air Shroud | 1x MCP-310-19006-0N |
| Backplane | 1x BPN-SAS-809TQ |
| Drive Trays | 4x MCP-220-00047-0B |
| Mounting Rails | 1 set MCP-290-00050-0N |
| Parts List |
| Cables | 1x CBL-0206L, 3x CBL-0226L, 1x CBL-0071L, 1x CBL-0277L, 1x CBL-0160L |
