Supermicro SSG-6028R-E1CR24N 2U Storage Barebone Dual Processor
Memory capacity of up to 3TB using 24 DIMM slots
Supporting Intel Xeon processor E5-2600 v4/v3 family
Equipped with 1600W redundant Titanium-level power supplies
Broadcom 3108 SAS3 onboard Hardware RAID 0, 1, 5, 6, 10, 50, 60
Barebone 2U SuperStorage Server - Supports up to two Intel Xeon E5-2600 v4/v3 processors - Supports up to 3.0TB DDR4 ECC 3DS LRDIMM up to 2400MHz, in 24x 288-pin slots - On-Board : Intel C612 chipset, LSI 3108 SAS3 12Gbps (Hardware RAID 0, 1, 5, 6, 10, 50, 60), SATA3 6Gbps (RAID 0, 1, 5, 10), SIOM support for flexible networking options, IPMI 2.0, VGA - Includes : 24x 3.5in Hot-swap SAS3/SATA3 drive bays, 2x 2.5in rear Hot-swap drive bays, SAS3 Hardware RAID Mezzanine card for X10DSC+ (AOM-S3108M-H8L-P), 2x Heatsinks (SNK-P0047PS), 1600W Redundant 80 Plus Titanium Level Power Supply with PMBus (2x PWS-1K62A-1R), MBD-X10DSC+ Motherboard, SC826SE1C4-R1K62 2U Chassis (Black)
This product is no longer available.
To maintain quality and integrity, this product is sold only as a completely-assembled system (with minimum 2 CPUs, 2 DIMMs, 6 HDDs and 1 NIC or SIOM card).
1. Dual socket R3 (LGA 2011) supports Intel® Xeon® processor E5-2600 v4 † /v3 family; QPI up to 9.6GT/s
2.Up to 3TB † ECC 3DS LRDIMM, up to DDR4- 2400 † MHz; 24x DIMM slots
3. 2 PCI-E 3.0 x16, 1 PCI-E 3.0 x8
4. SIOM for flexible networking options
5. 24x 3.5" Hot-swap SAS3/SATA3 drive bays; 2x 2.5" Hot-swap rear SATA drive bays
6. Onboard Broadcom 3108 SAS3 Hardware RAID RAID 0, 1, 5, 6, 10, 50, 60
7. Server remote management: IPMI 2.0 / KVM over LAN / Media over LAN
8. 5x 8cm hot-swap redundant PWM fans
9. 1600W Redundant Power Supplies Titanium Level (96%)
Extra Specifications for Supermicro SSG-6028R-E1CR24N 2U Storage Barebone Dual Processor
| Motherboard | ||
| Motherboard | Super X10DSC+ | |
| Processor/Cache | ||
| CPU | Dual Socket R3 (LGA 2011) | |
| Intel® Xeon® processor E5-2600 v4 † / v3 family (up to 145W TDP) * | ||
| Cores / Cache | Up to 22 Cores † / Up to 55MB † Cache | |
| System Bus | QPI up to 9.6 GT/s | |
| Note | † BIOS version 2.0 or above is required | |
| * Please contact Supermicro Technical Support for additional information about frequency optimized CPUs and specialized system optimization. | ||
| System Memory | ||
| Memory Capacity | 24x 288-pin DDR4 DIMM slots | |
| Up to 3TB † ECC 3DS LRDIMM, 512GB ECC RDIMM | ||
| Memory Type | 2400 † /2133/1866/1600MHz ECC DDR4 SDRAM 72-bit | |
| DIMM Sizes | LRDIMM: 64GB, 32GB | |
| 3DS LRDIMM: 128GB | ||
| RDIMM: 64GB, 32GB, 16GB, 8GB, 4GB | ||
| Memory Voltage | 1.2 V | |
| Error Detection | Corrects single-bit errors | |
| On-Board Devices | ||
| Chipset | Intel® C612 chipset | |
| SAS3 | Broadcom 3108 SAS3 onboard | |
| Hardware RAID 0, 1, 5, 6, 10, 50, 60 | ||
| SATA | SATA3 (6Gbps); RAID 0, 1, 5, 10 | |
| IPMI | Support for Intelligent Platform Management Interface v.2.0 | |
| IPMI 2.0 with virtual media over LAN and KVM-over-LAN support | ||
| ASPEED AST2400 BMC | ||
| Network Controllers | SIOM support for flexible networking options | |
| Graphics | ASPEED AST2400 BMC | |
| Input / Output | ||
| LAN | LAN ports via SIOM Add-On-Card | |
| USB | 3 USB 3.0 ports (2 rear + 1 Type A) | |
| Video | 1 VGA port | |
| Serial Port / Header | 1 Fast UART 16550 port / 1 Header | |
| Chassis | ||
| Form Factor | 2U Rackmount | |
| Model | CSE-826SE1C4-R1K62 | |
| Dimensions | ||
| Width | 17.2" (437mm) | |
| Height | 3.5" (89mm) | |
| Depth | 34" (863.6mm) | |
| With Cable Management Arm Installed: 41" (1041.4mm) | ||
| Available Colors | Black | |
| Front Panel | ||
| Buttons | Power On/Off button | |
| System Reset button | ||
| LEDs | System Information LED | |
| Hard drive activity LED | ||
| 2 Network activity LEDs | ||
| Power status LED | ||
| Power fail LED | ||
| Expansion Slots | ||
| PCI-Express | 2 PCI-E 3.0 x16 slots | |
| 1 PCI-E 3.0 x8 slot | ||
| Drive Bays | ||
| Hot-swap | 24x 3.5" Hot-swap SAS3/SATA3 drive bays | |
| 2x 2.5" rear Hot-swap SATA drive bays | ||
| Backplane | ||
| Backplane | Two 12 port SAS3 12G expander backplanes, each supporting up to 12x 2.5" SAS3 drives | |
| System Cooling | ||
| Fans | 5x 8cm hot-swap redundant PWM cooling fans | |
| Power Supply | ||
| Power Supply | 1600W Redundant Power Supplies with PMBus | |
| Total Output Power | 1600W/1000W | |
| Dimension (W x H x L) | 73.5 x 40 x 203 mm | |
| Input | 100-127Vac / 13 - 9A / 50-60Hz | |
| 200-240Vac / 10 - 8A / 50-60Hz | ||
| +12V | Max: 83.3A / Min: 0A (100-127Vac) | |
| Max: 133A / Min: 0A (200-240Vac) | ||
| 12Vsb | Max: 2.1A / Min: 0A | |
| Output Type | 25 Pairs Gold Finger Connector | |
| Certification | Titanium Level | |
| System BIOS | ||
| BIOS Type | 128Mb SPI Flash EEPROM with AMI BIOS | |
| BIOS Features | USB Keyboard support | |
| Plug and Play (PnP) | ||
| PCI 2.2 | ||
| SMBIOS 2.3 | ||
| ACPI 1.0 / 2.0 | ||
| UEFI | ||
| APM 1.2 | ||
| Operating Environment / Compliance | ||
| RoHS | RoHS Compliant | |
| Environmental Spec. | Operating Temperature: 10°C to 35°C (50°F to 95°F) | |
| Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) | ||
| Operating Relative Humidity: 8% to 90% (non-condensing) | ||
| Non-operating Relative Humidity: 5% to 95% (non-condensing) | ||
| Product SKUs | ||
| Product SKUs | SuperStorage 6028R-E1CR24N (Black) | |
| Name | Part Number | Qty. | Description | |
|---|---|---|---|---|
| Motherboard / Chassis | MBD-X10DSC+ | 1 | Super X10DSC+ Motherboard | |
| Motherboard / Chassis | CSE-826SE1C4-R1K62 | 1 | 2U Chassis | |
| Cable Management Arm | MCP-290-00086-0N | 1 | Cable Management Arm for 1U ball bearing Chassis | |
| Add-on Card / Module | AOM-S3108M-H8L-P | 1 | sas3 roc mez for X10dsc | |
| Backplane | BPN-SAS3-826SEL1-N4 | 2 | 12-port 2U Simply-Double SAS3 12Gbps single-expander backplane, support up to 8x 3.5-inch SAS3/SATA3 HDD and 4x NVMe/SAS3/SATA3 storage devices | |
| Cable 1 | CBL-PWEX-0702 | 1 | PWEX,2X4F/P4.2 TO 1X4F/P5.08/RA,32CM,18AWG,YEL,BLK*2,RED | |
| Cable 2 | CBL-SAST-0835 | 2 | SLIMLINE SAS to MiniSAS HD, INT, 100CM, 32AWG | |
| Cable 3 | CBL-SAST-0836 | 2 | MINI SAS HD,INT,SAS3 SSD,48CM,32AWG | |
| Heatsink / Retention | SNK-P0047PS | 2 | 1U Passive CPU Heat Sink for X9, X10 Systems Equipped w/ a Narrow ILM MB | |
| * Power Supply | PWS-1K62A-1R | 2 | AC-DC 1600W, Titanium Level, Redundancy, 1U, DC Output: +12V and +12Vs, 203 x 73.5 x 40 mm, AC Input: 90 - 264 VAC/47-63Hz, PMBus 1.2 with DSP controller,HF,RoHS/REACH | |
| * Power Distributor | PDB-PT226S-8824 | 1 | 12V 25pair connector inpu with special wires 12V/168A output | |
| * Cable 4 | CBL-0156L | 1 | CBL,FRONT CNTL,16 TO 16 PIN,RA,RND TUBE,40CM,28AWG | |
| * Cable 5 | CBL-0459L | 2 | LATCH CLAMP,AC POWER CORD | |
| * Cable 6 | CBL-CDAT-0728 | 1 | 4 Pin to 4 Pin I2C cable, 65cm, 26AWG, 4 wires, pinout 1-1, for vpp header(jnvi2c1),RoHS/REACH | |
| * Cable 7 | CBL-PWEX-0760 | 1 | PWR EXT,2X4F/P4.2 TO 2X4F/P4.2,CPU 12V,13CM,16AWG,RoHS/REACH | |
| * Cable 8 | CBL-PWEX-0901 | 2 | BPN PWEX,2X4F to 2X4F,GPU,P4.2,BLK*4,YEL*2,RED*2,33CM,18AWG, | |
| * Cable 9 | CBL-PWEX-0903 | 2 | BPN PWEX,2X4F to 2X4F,GPU,P4.2,BLK*4,YEL*2,RED*2,72CM,18AWG,For CSE-226STS-R1K62P1 only | |
| * FAN 1 | FAN-0168L4 | 5 | 80x80x38 mm, 13.5K RPM, Middle Cooling Fan for SC226S Chassis (48-bay) | |
| * Drive Tray(s) | MCP-220-00133-0B | 24 | Black gen 8 hot-swap 3.5\" HDD tray | |
| * Front Panel | MCP-280-00015-0N | 1 | Front control board for SC826 (inside the left handle),FP826 | |
| * Front Panel | MCP-280-00018-0N | 1 | SC826 front control board adapter | |
| * Drive Tray(s) | MCP-290-82607-0N | 1 | 826B/216B rear dummy cover for 2 X 2.5 |
