| Main Specifications |
| Device Type | SuperChassis |
| Dimensions (WxDxH) | Height 1.7" (43mm) x Width 17.2" (437mm) x Depth 25.6" (650mm) |
| Color | Black |
| Form Factor | 1U chassis support for max. motherboard size - 12" x 13" E-ATX |
| Processor |
| Compatible Processors | Dual Xeon Processors |
| Expansion / Connectivity |
| Expansion Slots Total (Free) | 1x full-height, full-length PCI expansion slot (Riser Card Required) |
| Peripheral Drives |
| DVD-ROM | Slim DVD-ROM drive (optional) |
| Drive Bays |
| Hot-swap | SAS or enterprise SATA HDD only recommended |
| 4x 3.5" SAS / SATA Hot-swap drive bays |
| Front Panel |
| Buttons | Power On/Off button, System Reset button |
| LEDs | Power LED, Hard drive activity LED, 2x Network activity LEDs, System Overheat LED |
| System Cooling |
| Fans | 2x 10cm PWM blower fans |
| 2x FAN-0135L4 |
| Operating Environment (System) |
| Operating Temperature Range | Operating Temperature Range: 5C ~ 35C (41F ~ 95F) |
| Non-Operating Temperature Range: -40C ~ 60C (-40F ~ 140F) |
| Operating Relative Humidity Range: 8% ~ 90% (non-condensing) |
| Non-Operating Relative Humidity Range: 5% - 95% (non-condensing) |
| Power Supply |
| Certification | 80PLUS Gold Certified |
| Power Supply | 600W AC multi output power supply w/ PFC |
| 1x PWS-601-1H |
| Regulatory (Power Supply) |
| Power Supply Safety / EMC | USA - UL listed, FCC, Canada - CUL listed, Europe/CE Mark, EN 60950/IEC 60950-Compliant |
| SAS / SATA Backplane |
| SAS / SATA Backplane | 1x 1U Serial ATA backplane |
| Standard Parts List |
| Accessory | 1x MCP-120-00053-0N |
| Chassis | 1x CSE-813T-600CB |
| Fan Holder | 1x MCP-320-81301-0N |
| Front Panel | 1x FPB-FP813-D |
| Peripheral Drive Covers | 1x CSE-PT93L-B |
| Rear Window | 1x CSE-RW-813-500C |
| Parts List - (Items Included) |
| Backplane | 1x BPN-SAS-815T |
| Drive Trays | 4x MCP-220-00075-0B |
| Mounting Rails | 1set MCP-290-00106-0N, 1set MCP-290-00102-0N |
| Parts List |
| Cables | 1x CBL-0180L-01, 1x CBL-0160L, 1x CBL-0071L |
| Miscellaneous |
| Compatible With | Server(s) for SC813T-600CB: 6017R-TDF+ |
