| On-Board Devices |
| Chipset | Intel i350-AM4 |
| Main Specifications |
| Device Type | SIOM Networking Adapters |
| Dimensions (WxDxH) | Card PCB dimensions: 92mm (3.62in) x 87.1mm (3.43in) (W x D) |
| Form Factor | Super I/O Module (SIOM) |
| Storage Controller |
| Connectivity Technology | Wired |
| Miscellaneous |
| Features | Jumbo Frames support |
| 1Gb/s Ethernet IEEE 802.3, 802.3u, 802.3ab PHY specifications Compliant |
| IEEE 1588 protocol and 802.1AS implementation |
| IEEE 802.3x and 802.3z compliant flow control support |
| Automatic cross-over detection function (MDI/MDI-X) |
| IEEE 802.3 auto-negotiation for speed, duplex, and flow control |
| Optimized for 2U / 4U TwinPro and Storage Servers |
| Cables Required | Support RJ45 Category 5/5e up to 100m |
| Designed For | 2U TwinPro SYS-2028TP-HTR-SIOM, 2U TwinPro SYS-2028TP-HC0R-SIOM, 2U TwinPro SYS-2028TP-HC1R-SIOM, 2U TwinPro SYS-6028TP-HTR-SIOM, 2U TwinPro SYS-6028TP-HC0R-SIOM, 2U TwinPro SYS-6028TP-HC1R-SIOM, 4U Storage SSG-6048R-E1CR90L |
| Included Accessories | 1x BKT-0087L, 1x BKT-0094L |
| RoHS | RoHS Compliant 6/6, Pb Free |
| Vendor Compatible Products | Supermicro motherboards with Super I/O Module slot |
| Supermicro server systems with Super I/O Module slot |
| Networking |
| Remote Management Protocol | Preboot eXecution Environment (PXE) support |
| Management Features | NC-SI for remote management |
| iSCSI Remote Boot Support |
| Asset Management support on Supermicro platforms |
| Controller asset tags such as part number, revision, serial number, and MAC addresses |
| Port Quantity | Quad RJ45 Ports |
| Virtualization Features | PC-SIG SR-IOV support |
| VM to VM Packet forwarding (Packet Loopback) |
| Flexible Port Partitioning |
| IEEE 802.1q VLAN support |
| IEEE 802.1q advanced packet filtering |
| Power |
| Comsumtion Operational | Typical 3.7W, Maximum 4.4W |
| Environmental Parameters |
| Operating Temperature | Operating temperature: 0C to 55C (32F to 131F) |
| Storage temperature: -40C to 70C (-40F to 158F) |
| Storage humidity: 90% non-condensing relative humidity at 35C |
| Software / System Requirements |
| OS Supports | FreeBSD |
| VMware |
| Windows Server 2012 R2, 2012, 2008 R2 (x64 Edition) |
| Windows 8.1, 8, 7 (x64 Edition) |
| RedHat Linux |
| SUSE Linux |
| UEFI |
