Main Specifications |
Dimensions (WxDxH) | Height 1.2" (30.48mm) x Width 4.94" (125.48mm) x Depth 23.2" (589.28mm) |
Type | MicroBlade |
Storage Capacity | 16GB |
Parts List |
Motherboard | B2SS1-CPU |
Processor |
Compatible Processors | Intel Xeon processor E3-1200 v5, CPU TDP up to 80W |
Processor Sockets | Single Socket H4 (LGA 1151) |
System Memory |
Error Detection | Corrects single-bit errors |
| Detects double-bit errors (using ECC memory) |
Memory Capacity | 4x DDR4 DIMM sockets |
| Supports up to 64GB DDR4 ECC VLP UDIMM |
Memory Voltage | 1.2 V |
Cache Memory |
Memory Type | 2133MHz ECC DDR4 UDIMM |
On-Board Devices |
Chipset | Intel C236 chipset |
IPMI | Support for Intelligent Platform Management Interface (IPMI) v.2.0 via Chassis Management Module (CMM) |
Network Controllers | Redundant 1GbE SDN switches with 40Gbps/10Gbps uplinks |
| Dual 1GbE LAN ports |
SAS | SAS3 (12Gbps) via Avago 3008 |
System BIOS |
BIOS Features | Plug and Play (PnP), APM 1.2, SMBIOS 2.7.1 |
BIOS Type | 128Mb SPI Flash EEPROM with AMI BIOS |
Front Panel |
LEDs | Power LED, Fault LED, Network Activity LED, UID / KVM LED |
Drive Bays |
Internal | 2x 2.5" SAS3 (12Gbps) HDD |
Environmental Parameters |
Operating Temperature | Non-operating Temperature: -40C to 70C (-40F to 158F) |
| Operating Relative Humidity: 8% to 90% (non-condensing) |
| Non-operating Relative Humidity: 5% to 95% (non-condensing) |
| Operating Temperature: 10C to 38C (50F to 100.4F) |
Electromagnetic Compatibility (EMC) |
Europe | EN55022 - Emissions, EN55024 - Immunity, EN61000-3-2 - Harmonics, EN61000-3-3 - Voltage Flicker, CE - EMC Directive 89/336/EEC |
United States / Canada | FCC- Emissions (US) Verification |
Parts List - (Items Included) |
Add-On Card | 1x AOM-BPNIO-MSC-P |
Air Shroud | 1x MCP-310-31405-0N |
Micro Blade Module Chassis | 1x MCP-620-31409-0N |
| 1x MCP-620-31411-0N |
| 1x MCP-620-31412-0N |
| 1x MCP-640-31409-0N |
Motherboard / Chassis | 1x MBD-B2SS1-CPU-P / 1x MCP-680-31408-0N |
