Optimized for demanding mainstream data center
2.10GHz Frequency, 48 Core/96 Thread, 105 MB Cache
Deliver hardware-enhanced security and workload acceleration
Support higher memory speeds and enhanced memory capacity
Processor 2.10GHz Xeon Scalable Platinum 8468 48-Core (96 Threads) FCLGA4677 105MB Smart Cache 7nm 350W 4th Generation, For 2S systems only - OEM, Tray
Advanced Technologies
Intel On-Demand Activation Model
Intel Data Streaming Accelerator (DSA)1 default devices
Intel Advanced Matrix Extensions (AMX)
Intel Speed Select Technology – Core Power
Intel Speed Select Technology – Turbo Frequency
Intel Deep Learning Boost (Intel DL Boost)
Intel Speed Select Technology - Base Frequency
High Priority Cores16
High Priority Core Frequency2.30 GHz
Low Priority Cores32
Low Priority Core Frequency1.90 GHz
Intel Resource Director Technology (Intel RDT)
Intel Speed Shift Technology
Intel Turbo Boost Technology 2.0
Intel Hyper-Threading Technology
Intel Transactional Synchronization Extensions
Intel 64
Instruction Set Extensions Intel AMX, Intel SSE4.2, Intel AVX, Intel AVX2, Intel AVX-512
# of AVX-512 FMA Units 2
Security & Reliability
Intel Crypto Acceleration
Intel QuickAssist Software Acceleration
Intel Platform Firmware Resilience Support
Intel Control-Flow Enforcement Technology
Intel Total Memory Encryption
Intel AES New Instructions
Intel Software Guard Extensions (Intel SGX) with Intel SPS
Default Maximum Enclave Page Cache (EPC) Size for Intel SGX512 GB
Intel OS GuardYes
Intel Trusted Execution Technology
Execute Disable Bit
Intel Boot Guard
Intel Run Sure Technology
Mode-based Execute Control (MBEC)
Intel Virtualization Technology (VT-x)
Intel Virtualization Technology for Directed I/O (VT-d)
Intel VT-x with Extended Page Tables (EPT)
| Main Specifications | ||
| Device Type | Server processor | |
| Processor Number | 8468 | |
| Clock Speed | 2.10 GHz | |
| Max Turbo Speed | 3.80 GHz | |
| Multi-Core Technology | 48-Cores | |
| Number of Threads | 96-Threads | |
| Intel UPI Speed | 16 GT/s | |
| QPI/UPI | UPI Links: 4 | |
| Manufacturing Process | 7 nm | |
| Product Collection | 4th Generation Intel Xeon Scalable Processors | |
| Code Name | Products formerly Sapphire Rapids | |
| Vertical Segment | Server | |
| Processor | ||
| Cache | 105 MB | |
| Thermal | ||
| Design Power | 350 W | |
| Memory Specifications | ||
| Max Memory Size (dependent on memory type) | 4 TB | |
| Memory Types | Up to DDR5 4800 MT/s 1DPC, Up to DDR5 4400 MT/s 2DPC | |
| Max # of Memory Channels | 8 | |
| ECC Memory Supported | Yes | |
| Expansion Options | ||
| Scalability | 2S | |
| PCI Express Revision | 5 | |
| Max # of PCI Express Lanes | 80 | |
| Package Specifications | ||
| Sockets Supported | FCLGA4677 | |
| Package Carrier | E1A | |
| DTS Max | 100 °C | |
| Case Temperature | 79°C | |
| Package Size | 77.5mm x 56.5mm | |
| Miscellaneous | ||
| Use Conditions | Server/Enterprise | |
| Package Type | OEM, Tray | |
| Warranty: | 1 year |
| Coverage: | Replacement or repair |
| Average Service Time: | 1-2 weeks |
| E-mail: | returnservices@wiredzone.com |
| If you need Technical Support for this item please contact: | |
| Provider: | Intel |
| Type of Support: | FULL |
| Phone No.: | 916-377-7000 |
| URL: | Click here for Manufacturer Website |
