- Supermicro X11SDV-12C-TP8F Motherboard Flex-ATX Intel Xeon D-2166NT, 12-Core SoC (System on Chip), up to 256GB ECC Reg DDR4 memory
Supermicro X11SDV-12C-TP8F Motherboard Flex-ATX Intel Xeon D-2166NT, 12-Core SoC (System on Chip), up to 256GB ECC Reg DDR4 memory
Includes 6 SATA3 (6Gbps) ports via SoC controller
Powered by an Intel Xeon D‑1577 12‑core processor
Features 2x 10G and 6x GbE LAN ports for flexible connectivity
Optimized for compact servers, networking, and storage appliances
Motherboard Flex-ATX Intel Xeon D-2166NT, 12-Core SoC (System on Chip), up to 256GB ECC Reg DDR4 memory, 12 SATA3 RAID 0,1,5,10, 4-port 1GbE, 2-port 10GbE Base-T, 2-port 10GbE SFP+, IPMI, VGA, TPM - MBD-X11SDV-12C-TP8F (Retail Box)
1. Supports 12V DC power input
2. Intel® Xeon® Processor D-2166NT, CPU TDP support Up to 85W TDP
3. Intel Quick Assist Technology
4. Up to 256GB Registered ECC RDIMM, DDR4-2133MHz; Up to 512GB LRDIMM LRDIMM, DDR4-2133MHz, in 4 DIMM slots
5. 1 PCIe 3.0 x8, 1 PCIe 3.0 x16 1 Mini-PCIe, 2 PCIe 3.0 NVMe x4 Internal Port(s) 1 M.2 M-Key SATA/PCIe 3.0 x4, 2280 1 M.2 B-Key SATA/PCIe 3.0 x2, 3042 U.2 Interface: 2 PCIe 3.0 x4
6. SoC controller for 12 SATA3 (6 Gbps) ports; RAID 0,1,5,10
7. Quad LAN with Intel® Ethernet Controller I350-AM4 Dual LAN with 10G SFP+ LAN via SoC Dual LAN with 10Gbase-T
8. 1 VGA D-Sub Connector port
9. System on Chip
Extra Specifications for Supermicro X11SDV-12C-TP8F Motherboard Flex-ATX Intel Xeon D-2166NT, 12-Core SoC (System on Chip), up to 256GB ECC Reg DDR4 memory
| System Memory | ||
| DIMM Sizes | LRDIMM: 16GB, 32GB, 64GB, 128GB | |
| RDIMM: 16GB, 32GB, 64GB, 128GB | ||
| Memory Capacity | 4 DIMM slots | |
| Up to 512GB ECC LRDIMM, DDR4-2133MHz; Up to 256GB ECC RDIMM, DDR4-2133MHz | ||
| Memory Type | 2666/2400/2133 MT/s ECC DDR4 LRDIMM, RDIMM (Operating speed up to 2133MHz) | |
| Memory Voltage | 1.2V | |
| On-Board Devices | ||
| Chipset | System on Chip | |
| IPMI | ASPEED AST2500 | |
| Network Controllers | Dual LAN with 10G SFP+ LAN via SoC | |
| Dual LAN with 10Gbase-T | ||
| Quad LAN with Intel® Ethernet Controller I350-AM4 | ||
| SATA | SoC controller for 12 SATA3 (6 Gbps) ports; RAID 0,1,5,10 | |
| Graphics | 1 ASPEED AST2500 BMC port(s) | |
| Input / Output | ||
| SATA | 4 SATA3 port(s) | |
| LAN | 4 RJ45 Gigabit Ethernet LAN ports | |
| 2 RJ45 10GBase-T ports | ||
| 2 10G SFP+ LAN ports | ||
| USB | 2 USB 3.0 port(s) (2 rear) | |
| 2 USB 2.0 port(s) (2 via header) | ||
| Video Output | 1 VGA D-Sub Connector port(s) | |
| Serial Port | 1 COM Port(s) (1 header) | |
| DOM | 1 Super DOM (Disk on Module) port with build power | |
| TPM | 1 TPM Header | |
| System BIOS | ||
| BIOS Features | ACPI 6.1 | |
| SMBIOS 3.1 | ||
| UEFI 2.6 | ||
| PCI FW 3.2 | ||
| BIOS Type | 128MB UEFI | |
| Management | ||
| Power Configurations | ACPI Power Management, +12V DC Power Input, CPU thermal trip support for processor protection | |
| Software | KVM with dedicated LAN, IPMI2.0 , Watchdog | |
| System Management Software | IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support | |
| PC Health Monitoring | ||
| FAN | 6x 4-pin fan headers (up to 6 fans) | |
| Thermal control tachometer fan connectors, System level control, PWM fan speed control, Fan speed control, Dual Cooling Zone, 6 fans with tachometer status monitoring, Overheat LED indication | ||
| Other Features | RoHS, M.2 NGFF connector, Dual Cooling Zones, CPU thermal trip support for processor protection, Chassis intrusion header, ATX Power connector, ACPI power management, 8-pin 12v DC power connector, 12V DC or ATX Power Source, Intel® QuickAssist Technology | |
| Voltage | System level control, Monitors CPU voltages, 5 -fan status, +5V standby, +5V, +3.3V, +12V, +1.5V, 5 (4-pin) | |
| Product SKUs | ||
| Product SKUs | MBD-X11SDV-12C-TP8F | |
| Physical Stats | ||
| Form Factor | Flex ATX | |
| Dimension | 9" x 7.25" (22.86cm x 18.42cm) | |
| Processor | ||
| CPU | Intel® Xeon® Processor D-2166NT | |
| Expansion Slots | ||
| PCIe | 1 PCIe 3.0 x8, | |
| 1 PCIe 3.0 x16 | ||
| 1 Mini-PCIe | ||
| M.2 | Key: M-Key, B-Key | |
| M.2 Interface: 1 SATA/PCIe 3.0 x4; 1 SATA/PCIe 3.0 x2 | ||
| Form Factor: 2280, 3042 | ||
| Operating Environment | ||
| Operating Temperature Range | 0°C - 60°C (32°F - 140°F) | |
| Operating Relative Humidity Range | 8% - 90% (non-condensing) | |
| Non Operating Relative Humidity Range | 5% - 95% (non-condensing) | |
| Warranty: | 3 years, 120 days advance replacement (doa) |
| Coverage: | Replacement or repair |
| Average Service Time: | Overnight replacement for 120 days, 2 weeks afterward |
| E-mail: | returnservices@wiredzone.com |
| If you need Technical Support for this item please contact: | |
| Provider: | Supermicro |
| Type of Support: | FULL |
| Phone No.: | 408-503-8000 |
| URL: | Click here for Manufacturer Website |
