- Toshiba MG07ACA12TE Hard Drive 12TB 7.2K RPM 3.5in SATA 6, 512e - MG07 Series
Toshiba MG07ACA12TE Hard Drive 12TB 7.2K RPM 3.5in SATA 6, 512e - MG07 Series
• Design for superior storage density
• 12TB - 24x7 operation - 512 Emulation
• File and Object-based storage infrastructure
• Low operational power - 7200 rpm Performance
Hard Drive 12TB 7.2K RPM, 3.5in, SATA 6Gb/s, 256M, 512e, Helium - OEM
• 7,200 rpm Performance
• SATA 6.0 Gbit/s Interface
• Industry Standard 3.5-inch 26.1 mm Form Factor
• Innovative 9-disk helium-sealed design for superior storage density
• Low operational power profile, providing excellent power efficiency (W/TB) for better TCO
Extra Specifications for Toshiba MG07ACA12TE Hard Drive 12TB 7.2K RPM 3.5in SATA 6, 512e - MG07 Series
| Main Specifications | ||
| Capacity | 12 TB | |
| Device Type | Hard drive - internal - 512 emulation | |
| Dimensions (WxDxH) | Width 101.85 x Height 26.1 x Length 147.0 mm | |
| Form Factor | 3.5-inch | |
| Interface Type | SATA-600 | |
| Weight | 720 g Max | |
| Hard Drive | ||
| Buffer Size | 256 MB | |
| Spindle Speed | 7200 RPM | |
| Performance | ||
| Drive Transfer Rate | 242 MiB/s Typ (Sustained) | |
| Load / Unload Cycles | 600,000 times | |
| Reliability | ||
| Availability (hrs/day x days/wk) | 24 hours/day, 7 days/week | |
| Non-Recoverable Errors | 10 error per 1016 bits read | |
| Miscellaneous | ||
| MTBF | 2.5 Million | |
| Applications | Tier 2 Business-Critical Servers and Storage Systems | |
| Mid-line / Nearline Business Critical Workloads | ||
| Cloud-scale Storage Infrastructure | ||
| Software-defined data center infrastructure | ||
| File- and Object-based storage infrastructure | ||
| Features | Innovative 9-disk helium-sealed design for superior storage density | |
| Low operational power profile, providing excellent power efficiency (W/TB) for better TCO | ||
| 7,200 rpm Performance | ||
| SATA 6.0 Gbit/s Interface | ||
| Industry Standard 3.5-inch 26.1 mm Form Factor | ||
| 550 Total TB Transferred per Year Workload Rating | ||
| Environmental Parameters | ||
| Humidity Range Operating | Operating: 5 % to 90 % R.H. (No condensation) - Non-Operating: 5 % to 95 % R.H. (No condensation) | |
| Min Operating Temperature | Ambient temperature Operating: 5 C to 55 C - Non-Operating: - 40 C to 70 C | |
| Shock Tolerance | Operating: 686 m/s2 { 70 G } ( 2 ms duration ) - Non-Operating: 2,450 m/s2 { 250 G } ( 2 ms duration ) | |
| Vibration Tolerance | Operating: 7.35 m/s2 { 0.75 G } ( 5 to 300 Hz ) | |
| Operating: 2.45 m/s2 { 0.25 G } ( 300 to 500 Hz ) | ||
| Non-Operating: 29.4 m/s2 { 3.0 G } ( 5 to 500 Hz ) | ||
| Power | ||
| Power Consumption | 4.25 W Typ (Idle - A) | |
