| Main Specifications |
| Device Type | SuperChassis |
| Dimensions (WxDxH) | Height 16.8" (426 mm) x Width 7" (178 mm)x Depth 20.9" (531 mm) |
| Color | Black |
| Form Factor | Mid-Tower chassis |
| Supported Mainboards | Supports for maximum motherboard sizes: 12" x 13" E-ATX and ATX |
| Weight | Net Weight 38 lbs (17.24 kg) - Gross Weight 40 lbs (18.14 kg) |
| Processor |
| Compatible Processors | Dual and Single Intel and AMD processors |
| Expansion / Connectivity |
| Expansion Slots Total (Free) | 7 full-height & full-length expansion slot(s) |
| Drive Bays |
| Hot-swap | 4 x 3.5" hot-swap SAS/SATA drive bay with SGPIO |
| Peripheral Drives |
| Peripheral Bay | 2 x standard 5.25" drive bay |
| 1 x 3.5" internal fixed drive bay |
| Front Panel |
| Buttons | Power On/Off button, System Reset button |
| LEDs | 1 Network Activity LEDs, HDD activity LED, Power LED, System Overheat LED |
| Networking |
| Ports | 2x USB 2.0 Port(s) |
| System Cooling |
| Fans | 1 x 12cm rear exhaust fan(s) |
| 1 x 9cm hot-swap cooling fan(s) |
| 1x FAN-0076L4, 1x FAN-0077L4 |
| Operating Environment (System) |
| Operating Temperature Range | Non-Operating Relative Humidity Range: 5% - 95% (non-condensing) |
| Operating Temperature Range: 5C - 35C (41F - 95F) |
| Non-Operating Temperature Range: -40C - 70C (-40F - 158F) |
| Operating Relative Humidity Range: 8% - 90% (non-condensing) |
| SATA / SAS Backplane |
| SATA / SAS Backplane | 4x3.5" SAS2/SATA3 backplane w/SES-II |
| Power Supply |
| Certification | 80PLUS Platinum Certified |
| Power Supply | PS2 668W Multi-output power supply 80PLUS Platinum |
| 1x PWS-668-PQ |
| Regulatory (Power Supply) |
| Power Supply Safety / EMC | BSMI, CCC, CE/EMC, FCC class B, TUV/CB, UL/CUL |
| Parts List - (Items Included) |
| Backplane | 1x CSE-SAS-733TQ |
| Parts List |
| Cables | 1x CBL-0049L, 1x CBL-0084, 1x CBL-0160L |
| Standard Parts List |
| Drive Tray | 4x MCP-220-00093-0B, 1x CSE-PT36-BOEM |
| Front Bezel | 1x MCP-210-73301-0B |
