Main Specifications |
Device Type | SuperChassis |
Dimensions (WxDxH) | Height 1.7" (43 mm) x Width 17.2" (437 mm) x Depth 25.6" (650 mm) |
Color | Black |
Form Factor | 1U Chassis |
Max Mainboard Size | Optimized for X11 WIO (W series) motherboards, support MB size up to 12.3" x 13.4" |
Weight | 36 lbs (16.33 kg) |
Processor |
Compatible Processors | Single and Dual Intel and AMD processors |
Expansion / Connectivity |
Expansion Slots Total (Free) | 1 low-profile expansion slot(s) |
| 2 full-height & full-length expansion slot(s) |
Drive Bays |
Hot-swap | 4 x 3.5" hot-swap SAS/SATA - SAS or enterprise SATA HDD only recommended |
Front Panel |
Buttons | Power On/Off button, System Reset Button, Unit Identification (UID) button |
LEDs | 2 Network Activity LEDs, Fan Fail/System Over Heat LED, HDD activity LED, Power Status LED, Unit Identification (UID) LED |
System Cooling |
Fans | 4 x 40x56mm counter-rotation PWM fan(s) |
| 4x FAN-0156L4 |
Parts List - (Items Included) |
Backplane | 1x BPN-SAS3-815TQ |
| 1U 4-Port 12Gbps Backplane Support 4x3.5 |
Air Shroud | 1x MCP-310-19002-0N |
Drive Trays | 4x MCP-220-00075-0B |
Mounting Rails | 1x MCP-290-00054-0N |
Parts | 1x MCP-120-00030-0N, 2x MCP-120-00053-0N |
Operating Environment (System) |
Operating Temperature Range | Non-Operating Relative Humidity Range: 5% - 95% (non-condensing) |
| Operating Temperature Range: 5C - 35C (41F - 95F) |
| Non-Operating Temperature Range: -40C - 70C (-40F - 158F) |
| Operating Relative Humidity Range: 8% - 90% (non-condensing) |
Power Supply |
Certification | 80PLUS Platinum Certified |
Power Supply | 1U Redundant 700/750W Single Output Power Supply Platinum level, 54.5mm width |
| 2x PWS-706P-1R, 1x MCP-250-81502-0N |
Regulatory (Power Supply) |
Power Supply Safety / EMC | BSMI, CCC, CE/EMC, FCC class A, TUV/CB, UL/CUL |
Standard Parts List |
Accessory | 1x CSE-PT93L-B, 1x CSE-PT0135, 2x MCP-340-00035-0B |
Front Panel | 1x FPB-FP815U |
Power Distributor | 1x PDB-PT112-S2424 |
Rear Window | 1x MCP-240-00098-0N |
Parts List |
Cables | 1x CBL-0335L |
Miscellaneous |
Compatible With | X11DDW-L, X11DDW-NT |
