- Supermicro CSE-829HE1C4-R1K62LPB Server Chassis 2U Rackmount
Supermicro CSE-829HE1C4-R1K62LPB Server Chassis 2U Rackmount
Support Dual and Single Intel and AMD processors
2U Chassis: Supports motherboards up to E-ATX, ATX
High-Density Storage: 16 x 3.5" hot-swap SAS3/SATA bays
Efficient Power: AC-DC 1600W Titanium Power Supply with PMbus
Rackmount 2U for Intel/AMD Single or Dual CPU motherboards. 7x Expansion Slots. 1600W Redundant 80 Plus Titanium Power Supply - Includes : 16x 3.5in Hot-Swap Drive bays, Mounting Rails Kit - SC829HE1C4-R1K62LPB (Black)
1. 2U chassis supports for maximum motherboard sizes - 13.68" x 13.4", E-ATX 12" x 13", ATX 12" x 10" motherboards
2. 16 x 3.5" hot-swap SAS3/SATA drive bay, optional 2 x 2.5" hot-swap SAS3/SATA drive bay
3. 12-Port 2U Backplane with Expander support up to 8 x 3.5" SAS3/SATA3 HDD/SDD and 4 x SAS3/SATA3/NVMe Storage Devices,HF,RoHS/REACH
4. 4-port internal SAS3 12Gbps backplane, support up to 4x 3.5-inch SAS3/SATA3 HDD/SSD
5. 7 low-profile expansion slot(s)
6. 4 x 80x38mm hot-swap cooling fan(s)
Extra Specifications for Supermicro CSE-829HE1C4-R1K62LPB Server Chassis 2U Rackmount
| Front Panel | ||
| Buttons | Power On/Off button | |
| System Reset Button | ||
| LEDs | Power Status LED | |
| System Information LED | ||
| Power Fail LED | ||
| 2 Network Activity LEDs | ||
| HDD Fail LED | ||
| Operating Environment (System) | ||
| Non-Operating Temperature Range | -40°C - 60°C (-40°F - 140°F) | |
| Operating Temperature Range | 5°C - 35°C (41°F - 95°F) | |
| Operating Relative Humidity Range | 8% - 90% (non-condensing) | |
| Non-Operating Relative Humidity Range | 5% - 95% (non-condensing) | |
| Power Supply | ||
| Certification | N/A | |
| Dimensions (L x W x H) | x x mm | |
| Power Distributor | PDB-PT829H-2824 | |
| O/P: 12V/120A | ||
| +5V Max: 45A | ||
| +3.3V Max: 24A | ||
| -12V Max: 0.6A | ||
| Product SKUs | ||
| Product SKUs | ||
| Form Factor | ||
| Form Factor | 2U chassis supports for maximum motherboard sizes - 13.68" x 13.4", E-ATX 12" x 13", ATX 12" x 10" motherboards | |
| Processor Support | ||
| Processor Support | Dual and Single Intel® and AMD processors | |
| Dimensions | ||
| Height | 3.5" (89 mm) | |
| Width | 17.2" (437 mm) | |
| Depth | 27.75" (705 mm) | |
| Net Weight | 41.5 lbs (18.82 kg) | |
| Gross Weight | 62 lbs (28.12 kg) | |
| Packaging (W x H x L) | 25.9" (658 mm) x 10.8" (274 mm) x 39.3" (998 mm) | |
| Available Color | Black | |
| Expansion Slots | ||
| Expansion Slots | 7 low-profile expansion slot(s) | |
| Drive Bays | ||
| Drive Bays | 16 x 3.5" hot-swap SAS3/SATA drive bay | |
| Optional 2 x 2.5" hot-swap SAS3/SATA drive bay | ||
| Backplane | ||
| Backplane | 12-Port 2U Backplane with Expander support up to 8 x 3.5" SAS3/SATA3 HDD/SDD and 4 x SAS3/SATA3/NVMe Storage Devices,HF,RoHS/REACH | |
| 4-port internal SAS3 12Gbps backplane, support up to 4x 3.5-inch SAS3/SATA3 HDD/SSD | ||
| Systems Cooling | ||
| Fans | 4 x 80x38mm hot-swap cooling fan(s) | |
| System Monitoring | ||
| System Monitoring | Chassis intrusion switch | |
| Name | Part Number | Price | Add to Cart | Qty. | Description | |
|---|---|---|---|---|---|---|
| Adaptor Bracket | MCP-120-82503-0N | $ 34.00 | 0 | Cable arm adapter for SC825LP,213LP (MCP-290-00073-0N required),HF,RoHS/REACH,PBF | ||
| Cable Management Arm | MCP-290-00073-0N | $ 81.50 | 0 | Supermicro Cable Management Arm for 2U, 3U and 4U chassis | ||
| HDD Tray Converter | MCP-220-00118-0B | $ 31.50 | 0 | Black gen-5.5 tool-less 3.5-to-2.5 converter drive tray,RoHS/REACH | ||
| HDD Tray Converter | MCP-220-00043-0N | $ 26.00 | 0 | Black hot-swap gen 4 3.5 to 2.5 HDD tray | ||
| HDD Kit | MCP-220-82616-0N | $ 89.00 | 0 | 12G 2.5x2 Drive Kit w/ Status LED (216B/826B/417B/846X/847B | ||
| Rail | MCP-290-00058-0N | $ 103.00 | 0 | Short rail set, quick release, 19.6"~26.9" Extendable Length | ||
| Tray(s) | MCP-220-00138-0B | $ 43.00 | 0 | Black gen-5.5 tool-less NVMe 3.5-to-2.5 drive tray, Orange tab | ||
| Cable | CBL-SAST-0972 | $ 33.50 | 0 | OCuLink controller to MiniSAS HD backplane V.91,INT,PCIe NVMe SSD, 70CM,34AWG | ||
| Cable | CBL-SAST-0929 | $ 47.50 | 0 | OCuLink controller to MiniSAS HD backplane V.91,INT,PCIe NVMe SSD, 57CM,34AWG |
| Warranty: | 3 years labor, 1 year parts, 120 days advance replacement (doa) |
| Coverage: | Replacement or repair |
| Average Service Time: | Overnight replacement for 120 days, 2 weeks afterward |
