- Supermicro CSE-E102 Server Chassis 1U Rackmount
Supermicro CSE-E102 Server Chassis 1U Rackmount
Embedded Compact Chassis for Intel/AMD Single CPU motherboards. Support 3.5in SBC MBD form factor, 1x 4cm high performance PWM fan, Optional 1 x 2.5in Internal Drive
1. Slim & Space-saving 3.5" SBC Chassis Design
2. Embedded Appliance Chassis
3. 1x 2.5" internal 7mm SSD support
4. Support 3.5" SBC MBD form factor
5. 1x 4cm Cooling Fan
6. Optional VESA/Wall-mount ready
Extra Specifications for Supermicro CSE-E102 Server Chassis 1U Rackmount
Processor Support | ||
Processor Support | Single Intel® and AMD processors | |
Front Panel | ||
Buttons | Power On/Off button | |
LEDs | Power LED | |
HDD activity LED | ||
Operating Environment (System) | ||
Operating Temperature Range | 0°C - 40°C (32°F - 104°F) | |
Non-Operating Temperature Range | -20°C - 60°C (-4°F 140°F) | |
Operating Relative Humidity Range | 10% - 85% (non-condensing) | |
Non-Operating Relative Humidity Range | 10% - 95% (non-condensing) | |
Product SKUs | ||
Product SKUs | ||
Form Factor | ||
Form Factor | 3.5" SBC | |
Dimensions | ||
Height | 1.7" (43 mm) | |
Width | 7.6" (193 mm) | |
Depth | 5.2" (132 mm) | |
Gross Weight | N/A | |
Packaging (W x H x L) | 15" (381 mm) x 10.87" (276 mm) x 5.59" (142 mm) | |
Available Color | Black | |
Drive Bays | ||
Drive Bays | Optional 1 x 2.5" Internal Drive | |
Systems Cooling | ||
Fans | 1 x 4cm high performance PWM fan(s) |
Name | Part Number | Price | Add to Cart | Qty. | Description | |
---|---|---|---|---|---|---|
Cable | CBL-CUSB-1045 | 0 | SERIAL, 2x DB9M TO 2X10F/P2.00,INT TO EXT,FLAT, 12CM, 28AWG | |||
Cable | CBL-PWEX-0982 | $ 17.00 | 0 | PWR EXT,1X4F/P2.50 TO SATA POWER, 25CM, 22AWG | ||
Cable | CBL-SAST-0881 | $ 17.00 | 0 | SATA,INT,6G,FLAT,ST-RA,25CM,30AWG,BLK,No Latch,RoHS | ||
Chassis parts | MCP-160-10202-0B | $ 17.50 | 0 | CSE-E102 Optional FP mylar with 4x Comport opening only | ||
Chassis parts | MCP-160-10203-0B | $ 17.50 | 0 | CSE-E102 Optional FP mylar with 4x comport and Audio port | ||
Chassis parts | MCP-160-10204-0B | $ 17.50 | 0 | CSE-E102 Optional FP mylar with Audio port only | ||
Power Adapter | MCP-250-10117-0N | $ 50.50 | 0 | 60W DC power adapter with US power cord 18AWG 6ft | ||
Power Adapter | MCP-250-10124-0N | 0 | AC to DC 40W lockable power adapter | |||
IO shield | MCP-260-10202-0B | 0 | CSE-E102 I/O shield for X11SSN | |||
IO shield | MCP-260-10201-0B | 0 | CSE-E102 I/O shield for A2SAN and X11SAN | |||
Chassis parts | MCP-290-10113-0B | 0 | wall mount/VESA mount |
Warranty: | 3 years labor, 1 year parts, 120 days advance replacement (doa) |
Coverage: | Replacement or repair |
Average Service Time: | Overnight replacement for 120 days, 2 weeks afterward |
