| System Memory |
| DIMM Sizes | 4GB, 8GB, 16GB |
| Memory Capacity | Up to 64GB Unbuffered non-ECC UDIMM, DDR4-3733MHz (OC), in 4 DIMM slots |
| Memory Type | 2400MHz/2133MHz DDR4 288-pin Non-ECC UDIMM |
| Memory Voltage | 1.2V |
| On-Board Devices |
| Chipset | Intel® Z270 Express |
| Graphics | Up to DP 1.2, up to HDMI 1.4b |
| Network Controllers | Single LAN with Intel® single Ethernet PHY i219V |
| SATA | Intel® Z270 Express controller for 6 SATA3 (6 Gbps) ports; RAID 0,1,5,10 |
| Audio | ALC 1150 HD Audio |
| Input / Output |
| LAN | 1 RJ45 Gigabit Ethernet LAN ports |
| Video Output | 1 HDMI port(s), 1 DP (DisplayPort) port(s), 1 DVI - D port(s) |
| USB | 2 USB 2.0 ports ( + 2 via header(s)), |
| 8 USB 3.0 ports (6 rear + 2 via header(s)), |
| 2 USB 3.1 ports (2 rear) |
| Serial Port / Header | 1 COM Port (1 header(s)) |
| TPM | 1 TPM Header |
| System BIOS |
| BIOS Features | ACPI 5.0 |
| USB Keyboard support |
| DMI (SMBIOS) 2.7 |
| BIOS Type | 128Mb SPI Flash EEPROM with AMI BIOS |
| Management |
| Power Configurations | ACPI Power Management |
| Control of power-on for recovery from AC power loss |
| Software | SuperDoctor® 5, Watchdog |
| PC Health Monitoring |
| FAN | 4x 4-pin fan headers (up to 4 fans), 4 fans with tachometer monitoring, Fan speed control, Low noise fan speed control, PWM fan speed control |
| LED | Suspend static indicator LED |
| Other Features | ACPI power management, ATX Power connector, Chassis intrusion detection, Chassis intrusion header, Control of power-on for recovery from AC power loss, RoHS, Voltage and Frequency Overclocking |
| Voltage | +12V, +3.3V, +5V, 1.05 (PCH), 1.2V (VDIMM), 5+2 Phase-switching voltage regulator, Chassis intrusion header, VBAT |
| Temperature | CPU thermal trip support |
| Product SKUs |
| Product SKUs | - Discontinued SKU (EOL). Please contact sales-rep for replacement SKUs. |
| Physical Stats |
| Form Factor | microATX |
| Dimensions | 9.6" x 9.6" (24.38cm x 24.38cm) |
| Processor/Cache |
| CPU | Intel® 6th/7th Generation Core i7/Corei5/Corei3/Pentium®/Celeron® series processor. |
| Single Socket H4 (LGA 1151) supported, CPU TDP support Up to 120W TDP |
| Expansion Slots |
| PCI-E | 2 PCI-E 3.0 x16 slots (16/NA or 8/8), |
| 1 PCI-E 3.0 x4 |
| M.2 | Interface: PCIe 3.0 x4 and PCIe 3.0 x4 |
| Form Factor: M-Key , M-Key 2280, 22110 (RAID 0,1 support) |
