Supermicro AOC-MCX556A-EDAT ConnectX-5 InfiniBand/Ethernet Adapter Card 100GbE Dual Port QSFP28

ConnectX-5 Ex InfiniBand/Ethernet adapter card
EDR IB (100Gb/s) and 100GbE, dual-port QSFP28

Mellanox ConnectX-5 InfiniBand/Ethernet Adapter Card, 100Gb/s and 100GbE, PCI Express Gen4, Dual QSFP28 InfiniBand and Ethernet (copper and optical), InfiniBand Data Rate: SDR/DDR/QDR/FDR/EDR - Ethernet Data Rate: 1/10/25/40/50/100 Gb/s, Low Profile, MCX556A-EDAT - RoHS-R6 Compliant

NVIDIA ConnectX-5 and ConnectX-5 Ex InfiniBand/Ethernet Dual QSFP28 port PCI Express x16 adapter cards. It provides details as to the interfaces of the board, specifications, required software and firmware for operating the board, and relevant documentation.

Extra Specifications for Supermicro AOC-MCX556A-EDAT ConnectX-5 InfiniBand/Ethernet Adapter Card 100GbE Dual Port QSFP28

Main Specifications
Device Type	InfiniBand/Ethernet Adapter Card
Form Factor	Plug-in Card
Interface (Bus) Type	PCI Express 4.0 x16
Dimensions (WxDxH)	2.71 in. x 5.6 in. (68.90mm x 142.24 mm) – low profile
Expansion / Connectivity
Interface Ports	Dual QSFP28 InfiniBand and Ethernet (copper and optical)
Performance
Internal Data Rate	InfiniBand: SDR/DDR/QDR/FDR/EDR
	Ethernet: 1/10/25/40/50/100 Gb/s
Miscellaneous
Environmental Compliance	RoHS-R6

Warranty:	3 years, 120 days advance replacement (doa)
Coverage:	Replacement or repair
Average Service Time:	Overnight replacement for 120 days, 2 weeks afterward
E-mail:	returnservices@wiredzone.com

If you need Technical Support for this item please contact:
Provider:	Mellanox
Type of Support:	FULL
Phone No.:	408-916-0055
URL:	Click here for Manufacturer Website
