• Designed for high-density storage solutions
• Enterprise-class; 24×7 environmental robustness
• 1TB capacity; 15mm z-height 2.5-inch form factor
• Max-capacity entry-level servers and blade servers
Hard Drive 1TB SAS 12Gb/s 7200RPM 2.5in, 128MB Cache, 512e, Internal - Avenger Series (OEM, Single Pack) - OEM
• Third-generation, enterprise-class reliability for 24×7 environmental robustness
• Up to 1TB capacity in 15mm z-height, 2.5-inch form factor for space-constrained
• Improved rotational vibration tolerance and head micro-actuation maximizes system availability and performance
• Lowest enterprise operating power and enhanced PowerChoice options for additional power savings during idle periods
• Highest efficiency with over 50% improvement in watts/TB, and 18% sequential performance improvement compared to the previous generation
• Designed for high-density storage solutions requiring environmentally sound low power consumption and low weight for maximum storage efficiency
| Main Specifications | ||
| Capacity | 1TB | |
| Device Type | Hard Drive - Internal - 5xx Emulation | |
| Dimensions (WxDxH) | 0.591 x 2.760 x 3.955 in | |
| Form Factor | 15mm z-height, 2.5-inch | |
| Interface | SAS 12Gb/s | |
| Weight | 0.419 Lb | |
| Hard Drive | ||
| Buffer Size | 128MB Cache | |
| Spindle Speed | 7200RPM | |
| Networking | ||
| Port Quantity | Dual port | |
| Performance | ||
| Average Latency | 4.16 ms | |
| Max Sustainable Transfer Rate | 136 | |
| Miscellaneous | ||
| MTBF | 2.0 million | |
| Applications | Cloud Computing | |
| Enterprise backup and restoreD2D, virtual tape | ||
| Storage-hungry business applications | ||
| Storage area networks (SAN) and network attached storage (NAS) | ||
| Maximum-capacity entry-level servers and blade servers | ||
| Rich media content storage | ||
| Reliability | ||
| Non-Recoverable Errors | 1 sector per 10E15 | |
| Power-On Hours per Year | 8760 | |
| Environmental Parameters | ||
| Vibration Tolerance | Vibration, Operating, 5Hz to 500Hz (Gs): 0.5 | |
| Vibration, Nonoperating, 5Hz to 500Hz (Gs): 3.0 | ||
| Shock, Operating, 2ms (Gs): 25 | ||
| Shock, Nonoperating, 2ms (Gs): 400 | ||
| Acoustics, Typical Idle (bels): 2.8 | ||
| Acoustics, Typical Seek (bels): 3.2 | ||
| Min Operating Temperature | Operating (C): 5 to 55 | |
| Power | ||
| Idle (W) | 3.29 | |
| Requirement | +12V and +5V | |
| Warranty: | 5 years |
| Coverage: | Replacement or repair |
| Average Service Time: | 1-2 weeks |
| E-mail: | returnservices@wiredzone.com |
| If you need Technical Support for this item please contact: | |
| Provider: | Seagate |
| Type of Support: | FULL |
| Phone No.: | 800.SEAGATE |
| URL: | Click here for Manufacturer Website |
