  1. Products
  2. Seagate ST2000NM003A 2TB Hard Drive SAS3 12Gb/s 7200RPM 3.5-Inch 256MB 512N - Exos 7E8 Series
Seagate ST2000NM003A 2TB Hard Drive SAS3 12Gb/s 7200RPM 3.5-Inch 256MB 512N - Exos 7E8 Series

Seagate ST2000NM003A 2TB Hard Drive SAS3 12Gb/s 7200RPM 3.5-Inch 256MB 512N - Exos 7E8 Series

• Backed by a 2 million hour MTBF rating
• Low TCO for demanding 24×7 operations
• Vertical; horizontal; or top down mounting
• High performance; high capacity data storage

Hard Drive 2TB SAS3 12Gb/s 7.2K RPM 3.5in 256MB Cache, 512N - Cimarron Series - Enterprise Class (Bulk, OEM) - OEM

Contact us for volume discounts

    This combination does not exist.

    PreOrder
    1 lb
    Email For Price

    • Power Save
    • Embedded servo design
    • Jumperless configuration
    • 128 - deep task set (queue)
    • Dedicated head load/unload zone
    • Vertical, horizontal, or top down mounting
    • Flawed logical block reallocation at format time
    • Firmware downloadable using the SAS interface
    • No preventive maintenance or adjustments required
    • 3.0 / 6.0/12.0 Gb Serial Attached SCSI (SAS) interface
    • Self diagnostics performed when power is applied to the drive
    • Integrated dual port SAS controller supporting the SCSI protocol

    Extra Specifications for Seagate ST2000NM003A 2TB Hard Drive SAS3 12Gb/s 7200RPM 3.5-Inch 256MB 512N - Exos 7E8 Series

    Main Specifications
    Capacity2TB
    Device TypeHard drive - internal - Format (512n SAS)
    Dimensions (WxDxH)Height 1.028 x Width 4.010 x Depth 5.787 in
    Form Factor3.5in
    Weight1.58 lbs
    InterfaceSAS3 12Gb/s
    Interface TypeDual
    Included Qty5
    Optical Storage
    Buffer Size256MB Cache
    Hard Drive
    Spindle Speed7200
    Performance
    Average Latency4.16
    Interface Access Speed (Gb/s)12.0, 6.0, 3.0
    Max Sustainable Transfer Rate215MB/s
    Rotational Vibration12.5
    Reliability
    Bytes per Sector512
    Non-Recoverable Errors1 sector per 10E15
    Power-On Hours per Year8760
    Annual Failure Rate (AFR)0.44%
    Miscellaneous
    MTBF2,000,000hr
    FeaturesProtection Information (T10 DIF), Humidity Humidity Sensor, SuperParity, Low Halogen, PowerChoice Technology, PowerBalance Technology, 256 Cache Multisegmented (MB), Advanced Write Caching (Internal NOR flash)
    Environmental Parameters
    Min Operating TemperatureTemperature, Operating (C): 5C 60C
    Shock, Operating Read/Write (Gs): 70/40Gs
    Shock, Nonoperating, 1ms/2ms (Gs): 150/300
    Power
    Average Operating Power10.09W
    Idle (W)4.86W
    Requirement+12 V and +5 V

    Warranty:3 years
    Coverage:Replacement or repair
    Average Service Time:1-2 weeks
    E-mail:returnservices@wiredzone.com

    If you need Technical Support for this item please contact:

    Provider:Seagate
    Type of Support:FULL
    Phone No.:800.SEAGATE
    URL:Click here for Manufacturer Website
